Introduction
Top parts
21. Presser foot pressure dial
22. Thread guides
23. Spool caps
24. Hole for auxiliary spool pin
25. Bobbin winder lever and bobbin
spindle
26. Take-up lever
27. Thread tension discs
28. Thread tension dial
29. Bobbin winder tension disc
30. Stylus (ambition™ 1.5)
31. Bobbin thread cutter
Rear side
32. Main switch, connectors for power cord and
foot control
33. Handle
34. Presser foot lift
35. IDT™
36. Slide for lowering the feed dogs
Accessory tray
The accessory tray features special compartments
for presser feet and bobbins, plus space for needles
and other accessories. Store the accessories in the
tray so they are easily accessible.
37. Space for accessories
38. Removable tray for presser feet
39. Removable bobbin holder
21
26 27 28 29 30 31
22 23 24 25
32
34
35
33
36
37
38
39
