Operating Manual | Attachment and Installation Cooling Units | Standard Controller (SC) – 400 / 460 V, 3~ | 086100125 23/66
3.7.3 Dimensions
Designation Unit Model DTI / DTS 6801
Height
mm DTI: 1540
DTS: 1548
Width
mm 485
Depth with cover (standard)
mm 372
Installation depth DTI
mm 120
Weight
kg DTI: 90
DTS: 94
Installation attitude
— Vertical
Unit construction
— Standard: Steel sheet
Option: With stainless-steel cover
Tab. 7: Dimensions and weight model DTI / DTS 6801
3.7.4 Other unit data
Designation
Anti-corrosion protection
Standard: Galvanized, electrostatically powder-
coated (200°C)
Variant: Stainless-steel cover (material 1.4301, grounded)
Housing protection type (according to EN 60529) When used as intended:
• IP 55 internal – against the switch cabinet.
• IP 24 internal – against the environment.
