Operating Manual | Attachment and Installation Cooling Units | Standard Controller (SC) – 400 / 460 V, 3~ | 086100125 39/66
4.6.4.2 DIP-switch setting possibilities
NOTE
The cooling unit carries voltage if the red LED light on the controller is flashing. Always make sure that there is no voltage on
the unit before carrying out any work on the electrical connections.
DIP-switch Temperatures in °C
DIP-switch 4 OFF
Temperatures in °F
DIP-switch 4 ON
1 2 3 Setpoint Max. limit Setpoint Max. limit
OFF
OFF
OFF
25 °C
45 °C
77 °F
113 °F
ON
OFF
OFF
30 °C
45 °C
86 °F
113 °F
OFF
ON
OFF
35 °C
45 °C
95 °F
113 °F
ON
ON
OFF
35 °C
50 °C
95 °F
122 °F
OFF
OFF
ON
40 °C
50 °C
104 °F
122 °F
ON
OFF
ON
40 °C
55 °C
104 °F
131 °F
OFF
ON
ON
45 °C
55 °C
113 °F
131 °F
ON
ON
ON
45 °C
60 °C
113 °F
140 °F
Tab. 9: DIP-switch setting possibilities
NOTE
The cooling unit must be switched off and on to accept the changed setting.
