Phase 2 SRG-4600 - Standard Configuration; Turning On;Off Battery Switch; Battery Charging


StandardConfiguration
Name Qty
SRG-4600 main unit 1
Standard pickup(stylus) 1
Roughness specimen w/Holder 1
Stylus Nose Protector 1
Leveling Plates 1
A/C Adapter 1
Screw Driver 1

TurningOn/OffBatteryswitch
Thepowerswitchisontherightsideoftheinstrument.Whenpoweringoffforanextended
periodoftime,thisswitchshouldbeplacedtotheOFFpositiontocutoffpowersupply.The
SRG‐4600willautomaticallypoweronwhentheswitchismovedtotheONposition.

BatteryCharging
ThereisabatterysymbolinthetoprightcorneroftheSRG‐4600.Whenallofthebars
insidethesymboldisappear,thebatteryislowandtheunitmustbechargedup.
Typically,chargingtimeisapproximately3hours.
