Phase 2 SRG-4600 - Saving and Maintenance; Saving Test Results; Maintenance Procedures

To view your reading in other parameters, press the UP arrow button after your test is complete. You
will see all parameters as shown below:
SavingTestResults
1) Saving test results
Once the value is shown on the display, press the MEM button. Now press the Right arrow
button to go to the next numerical file that shows “empty” and press the
buttontosaveit.The
unitwillimmediatelyreturntothemaintestingdisplay.
Maintenance:
Stylus:
1) After completion of measuring work, please remove stylus from unit and return to case.
2) The stylus is extremely sensitive. Please don’t touch the tip or run it across a surface that hasn’t been cleaned.
These are also sensitive to high humidity. Please store in dry cool place.
Main Unit:
1） Always keep clean using a soft cloth. Do not use harsh cleaners on this as it will diminish the finish.
2） The SRG-4500 is a precise sensitive instrument and should be handled accordingly.
Battery:
1） Battery power is shown on the top right side of the display when in main measurement screen.
When the battery symbol is empty, its time to recharge the unit.
2） Approx. charging time is 3 hours.
Calibration Reference Standard:
1) Always keep this clean. Store in carry case when not in use.
2) Avoid scratches to the work area surface of the standard
Ra=3.655µm
Rq=3.793µm 
Rz=7.014µm 
Rmax=9.198µm
Rt=9.198µm 
RS=0.0930µm 
RSm=0.0909µm
Rmr=59.1%
Rpc=110.0cm
Use of supplied KEYFOB
PresstheBbuttontobringup
theLevelingDisplay.Besurethat
thearrowispointingonorvery
closetothe“0”onthegrid.
Thisfunctionsameas
“enter”onthekeypad.
Onceparametersareset,pressthe“A”
buttononthekeyfobtostartthe
measurement

p
rocess.
