Phase 2 SRG-4600 - Parameter Settings; Measure Set; Print Result; Calibration

3)ParameterSettings:

WhileMeasureSetishighlighted,Pressthe buttontoaccessandchangeallofthesettings
fortakingatest.




WhilePrintResultishighlighted,Pressthe buttontoaccessandchangeallofthesettings
forprintingresults.(Printermustbeselectedtoaccesssomeparameters)
WhileCalibrationishighlighted,Pressthe buttontoaccessandchangethesettingsrangefor
yourcalibration.
lr(ƛc):0.8mm (samplinglength) selectable
ln:lr*5   (assessmentlength)selectable
Range:+/‐40µm (rangeofyourapplication)
Filter:RC (filters)selectable
Standard:Ansi (Applicablestandards)selectable
DisplayR:Ra (Roughnessparameter)selectable
C(Rmr):75% (materialratiocurve)selectable
C(Rpc):000.00µm (materialdirectprofile)selectable
Unit:Metric (inch/metricselectable)
PrintRa,R willdisplayRavalueonprintout
PrintR&Prof willdisplayRavalue&Profile
PrintSelfR willdisplayself
SelfR..Set Chooseparametersforprintout
PROF:Ordinary showsstandardordetailedprofile
PrinterPair Bluetoothprintersetpairing
+/‐20µm: 00%
+/‐40µm: 02%
+/‐80µm: 00%
+/‐160µm: 00%
