Table 25 – Optional Circuit Breaker Wire Size and Torque
Models
Circuit Breaker
Family
Min Max
Min Torque
(in-lb)
Wire
Strip
PT007
PT010
PT407
PT410
PT415
PT420
PT430
LS UTE100
14 10 31.9
0.7”
8 39.9
6 3 47.8
2 1 55.7
PT020
PT440
LS UTS150
14 36.2
1.01”
12 10 47.8
8 2/0 133.6
PT030
PT450
PT460
PT475
LS UTS250
1/0 2/0 254.9
1.27”
3/0 4/0 350.5
250
kcmil
300
kcmil
350.5
PT040
PT050
LS UTS400
1/0
300
kcmil
358.4
1.76”
PT4100
PT4150
PT4175
350
kcmil
600
kcmil
477.9
Connecting to Field Wiring Terminals
Open the front door of the enclosure to gain access to the wiring panel. See Figure 6 -
Figure 10.
Figure 6 – PT Small Frame Field Wiring
Terminals
Figure 7 – PT Medium Frame Field Wiring
Terminals
