SPECIFICATIONS
Product name Ultra-Low Temperature Freezer
MDF-U700VX
Ultra-Low Temperature Freezer
MDF-U700VXC
External dimensions W1010 mm x D870 mm x H2010 mm
Internal dimensions W870 mm x D600 mm x H1400 mm
Effective capacity 728 L
Exterior Painted steel
Interior Painted steel
Outer door Painted steel
Inner door ABS resin panel with stainless frame, 2 doors
Shelf Stainless steel, 3 shelves (adjustable)
Inner dimension; W848 mm x D533 mm, Load; Max. 50 kg/shelf
Access port 17 mm diameter, 3 locations (back, 2 bottoms)
Insulation Vacuum insulation panel + Rigid polyurethane foamed-in place
Compressor A Compressor; Hermetic type, Output; 1100 W
B Compressor; Hermetic type, Output; 1100 W
Evaporator Tube on sheet type
Condenser Finless tube type
Refrigerant HFC mixed refrigerant
Temperature controller Microcomputer control system
Temperature display Digital display
Thermal sensor Platinum resistance (Pt 1000 Ω)
Alarm High temp. alarm, Low temp. alarm, Power failure alarm,
Door alarm, Sensor abnormality, Fan motor abnormality,
Condenser temp. abnormality, Cooling circuit abnormality
Remote alarm contact Allowable contact capacity: DC 30 V, 2 A
Battery Nickel-metal-hydride battery, DC 6 V, 1100 mAh, Auto-recharge
Accessories 1 set of key, 1 scraper, 1 stick for air intake port cleaning, Clip
Weight 375 kg 383 kg
Voltage booster None Built-in
Optional component
Temperature recorder (MTR-G85C),
Temperature recorder + Recorder fixing (MTR-85H + MDF-S3085),
Small inner door (MDF-7ID),
Interface board (MTR-480, MTR-L03)*,
Inventory rack (IR-220U, IR-224U),
Backup cooling kit (CVK-UB2, CVK-UB2I): LCO
2
Note:
• Design or specifications will be subject to change without notice.
• Refer to the updated catalog when ordering an optional component.
• About 3 days operation of a ultra-low temperature freezer is necessary to full charge the battery.
* For the data acquisition system MTR-5000 user only. Contact our sales representative or agent for purchase.
