SPECIFICATIONS
Product name Ultra-Low Temperature Freezer
MDF-U76V
External dimensions W1010 mm x D870 mm x H1990 mm
Internal dimensions W870 mm x D600 mm x H1400 mm
Effective capacity 728 L
Exterior Painted steel
Interior Painted steel
Outer door Painted steel
Inner door ABS resin panel with stainless frame, 2 doors
Shelf
Stainless steel, 3 shelves (adjustable)
Inner dimension; W848 mm x D533 mm, Load; 50 kg/shelf
Access port 17 mm diameter, 2 locations (back, bottom x 1)
Insulation Vacuum insulation panel + Rigid polyurethane foamed-in place
Compressor
High stage side; Output;750 W
Low stage side; Output;750 W
(AC 230 V/240 V, 50 Hz)
Evaporator Tube on sheet type
Condenser High stage side; Fin and tube type, Low stage side; Shell and tube type
Refrigerant High stage side; R-404A, Low stage side; R-508B
Temperature controller Microcomputer control system
Temperature display Digital display
Thermal sensor Platinum resistance (Pt 1000 ȍ)
Alarm
High temp. alarm, Low temp. alarm, Power failure alarm
Door alarm, Filter alarm
Remote alarm contact Allowable contact capacity: DC 30 V, 2 A *(3)
Battery Nickel-metal-hydride battery, DC 6 V, 1100 mAh, Auto-recharge
Accessories 1 set of key, 1 scraper, 1stick for air intake port cleaning
Weight 360 kg
Optional component Temperature recorder (MTR-G85C)*(1),
Small inner door (MDF-7ID),
Interface board (MTR-480, MTR-L03)*(2), *(3)
Inventory rack (IR-220U, IR-224U),
Backup cooling kit (CVK-UB2): LCO
2,
(CVK-UBN2): LN
2
Note:
• Design or specifications will be subject to change without notice.
• Refer to the updated catalog when ordering an optional component.
*(1): Power source of the temperature recorder shall be 220 V.
*(2): For the data acquisition system MTR-5000 user only. Contact our sales representative or agent
for purchase.
*(3): It is recommended to use standard signal and interface cables with a maximum length of 30
meters.
