107T6 CRT
59
1.0 Introduction
This document is related to the 17
AUTOSCAN (VGA above and Max. resolution
1280X1024 by 60HZ refresh) color monitor for world-wide destination.
2.0 General description
The AUTOSCAN analog color monitor is specified as a display peripheral within
an IBM PC, PS/2 ,VGA and advance VGA compatible system.
The AUTOSCAN analog color monitor is to operate at horizontal line rates
between 30 to 71 KHz and refreshment rate between 50 to 160 Hz, can be applied to all
RGB analog computers within this scanning frequencies.
The AUTOSCAN analog color monitor is intended to be a finished product,
basically a display device mounted inside a plastic enclosure which provides the aesthetic
mechanical, ergonomic and safety requirements.
2.1 General condition
The unit will produce a usable image after switching-on, measurements are to be carried out
with a full stabilized set after 30 minutes warm-up at room temperature of 25 degree C.
Repetitive power on/off cycles are allowed though should be avoided within 4 sec.
3.0 Electrical characteristics
3.1 Signal interface
The AUTOSCAN analog color display has an analog video interface to operates at a
multi-frequencies timing in several display modes.
3.1.1 Input requirements
A. Input signals
Video : Analog level
Sync. : Separate sync. with TTL level
Polarity : Positive or negative
B. Signal input level
Video : 0.7 Vp-p 75 ohms (for individual of R,G and B signals must not
deviate 0.015 Vp-p from each other for balance of white pattern)
Sync : TTL level
(between 0 and 0.6 V to be considered as low level, between 2.3 and 5.0 V
as high level)
C. Impedance
Video : Terminated with 75 ohms
Sync : Terminated with 4.7K ohms pull down resistors.
Go to cover page
4
BRAND : PHILIPS
TYPE :107T60/00
8639 000 15483
2004-04-16
2004-04-16
31
17" V32 GS4 107T6-71K CMTR
Wayn e Lin
GENERAL PRODUCT SPECIFICATION
