60
107T6 CRT
5
GENERAL PRODUCT SPECIFICATION
3.1.2 Signals input
The input video signals are applied to the display device through a video cable which is
fixed to the monitor (standard cable length 1. 5M).
Video input cable :
15 pin D-shell male connector type AMP 211350-1(3 rows) or equivalent, with pin
assignment as follows :
Pin assignment of 15P D-SUB connector
Pin nbr. Assignment
P1 Red video input
P2 Green video input
P3 Blue video input
P4 GND
P5 For selftest (PC Ground)
P6 Red video ground
P7 Green video ground
P8 Blue video ground
P9 DDC5VfromPC
P10Sync ground
P11 GND
P12 Bi-directional Data (SDA)
P13 H SYNC
P14 V SYNC (VCLK)
P15Data clock (SCL)
3.1.3 Factory preset modes:
Factory preset modes : 8
Resolution H. freq. V. freq. H. V.
1. 72
0 x400 31.5 KHz 70Hz (VGA)-+
2. 640 x480 31.47 KHz 60Hz (VGA)--
3. 640 x480 43.3 KHz 85Hz (VESA)- -
4. 800 x 600 46.9 KHz 75Hz (VESA)+ +
5.800 x 600 53.67KHz 85Hz (VESA)+ +
6.1024 x 768 60.0 KHz 75Hz (VESA)+ +
7. 1024 x 768 68.7 KHz 85Hz (VESA)+ +
8. 1280 x1024 64.0 KHz 60Hz (VESA)+ +
