107T6 CRT
15
GENERAL PRODUCT SPECIFICATION
Band I : 5 to 2K HZ.
Band II :2Kto400KHZ.
Test procedure according to low emission and E.S.P. test method.
3.11 Display data channel : DDC2B (VESA STANDARD)
The DDC HEX Data (refer sheet 190)shouldbewrittenintothe
DDC IC (24LC21 or equivalent)
4.0Display image (CRT facing east)
The monitor is aligned in a magnetic cage having the
following magnetic field components :
Northern Hemisphere : H = 0,V= 450 mG,Z=0
Southern Hemisphere : H = 0,V=-500 mG,Z=0
Equatorial : H = 0,V= 0 mG,Z=0
Conditions for visual testing, unless otherwise stated:
Input video signal - 700 mVpp cross hatch
Brightness control - center(50%)
Contrast control - maximum(100%)
4.1Display resolutions
See 3.1.3
4.2 Image size (F
or preset modes only)
The dimensions of guaranteed display area to be measured along the picture center of
horizontal and vertical axis of the screen as listed below: (preset modes only, refer
to fig. 1)
Width : 306 ± 3mm
Height : 230 ± 3mm
4.3 Image centering deviation (For preset modes only)
With respect to fig. 2, the target relationships are the following :
|A-B|£ 5 mm |C- D| £ 5 mm
Note : This centering is adjustable by the end-user.
4.4 Picture shift control range (For preset modes only)
H-shift range : ± 10 mm min.
V-shift range : ± 10 mm min.
