107T6 CRT
71
4.5 Picture tilt
With respect to Fig. 3, Tilt to be measured on extremes of center line from bezel.
|A- B|: £ 2mm
4.6 Geometrical distortions (For preset modes only)
It is acceptable that pincushion, trapezoid, rhomboid,
rotation and various waves distortions must remain within
the limits of tolerance as in Fig. 4,
whereA=B=2.0mm.
C=D=2.0mm.
The waviness of any vertical or horizontal shall be less than 1.0 mm over a 50 mm distance.
4.7 Image non-linearity (For preset modes only)
Apply cross-hatch pattern with
12 equal blocks along horizontal axis,
9 equal blocks along vertical axis. (see Fig. 1)
Overall : £ 10%
Adjacen: £ 6 %
Xmax. - Xmin
H. non-linearity = x 100%
(Xmax + Xmin)/2
Ymax. - Ymin
V. non-linearity = x 100%
(Ymax + Ymin)/2
4.8 Mis-convergence
The maximum convergence error to be measured on a white spot or white display line to
represents the maximum distance between the energy centers of any two primary colors
(See Fig. 6). For 31.5kHz modes B Zone : 0.4mm.
CONVERGENCE SPEC.
Zones 0.25 mm CRT
Zone C 0.15mm
Zone A 0.25 mm
Zone B 0.35 mm
Go to cover page
GENERAL PRODUCT SPECIFICATION
BRAND : PHILIPS
TYPE :107T60/00
8639 000 15483
2004-04-19
2004-04-16
31
Wayn e Lin
17" V32 GS4 107T6-71K CMTR
