51
170S6 LCD
General Product Specification
8639 000 16148
2004-12-15
590
9
26
Peter.V
202P Gs3 CM25
17 inch LCD Monitor
TYPE : 170S6FG/00
BRAND : PHILIPS
2004-12-15
3.3 Timing requirement
3.3.1Mode storing capacity
(1) Factorypreset modes. :15
(2) Preset modes. : 34
3.3.2Factory/Presettimings
Thefactorysettings ofsize and centeringareaccording to the reference timing charts
(See as below)
MODE NO. 123 4
RESOLUTION 640 x350 720 x 400 640 x 480 640 x 480
Dot clock(MH z) 25.175 28.321 25.175 30.24
f h 31.469kHz31.468kHz31.5kHz35 kHz
A (us) 31.778(800 dots) 31.78(900dots) 31.778(800 dots) 28.571 (864 dots)
B (us) 3.813(96 dots) 3.813(108dots) 3.813( 96 dots) 2.116 ( 64 dots)
C (us) 1.907(48dots) 1.907(54dots) 1.907( 48dots) 3.175( 96 dots)
D (us) 25.422(640 dots) 25.42(720dots) 25.422( 640 dots) 21.164( 640 dots)
E (us) 0.636(16 dots) 0.636(18dots) 0.636( 16 dots) 2.116( 64 dots)
fv 70Hz(70.09) 70Hz(70.085) 60Hz 67Hz
O(ms) 14.27(449 lines) 14.27(449 lines) 16.683 (525 lines) 15 (525 lines)
P (ms) 0.064(2 lines) 0.064(2 lines) 0.064 ( 2 lines) 0.086(3 lines)
Q(ms) 1.907(60 lines) 1.112(34 lines) 1.049 (33 lines) 1.114(39 lines)
R (ms) 11.12(350 lines) 12.71(400 lines) 15.253(480 lines) 13.714(480 lines)
S (ms) 1.175(37 lines) 0.381(13lines) 0.317 ( 10
line)
0.086(3line)
SYNC. H/V+/- -/+ -/- -/-
POLARITY
SEP . SYNC Y Y Y Y
