170S6 LCD
General Product Specification
8639 000 16148
2004-12-15
590
10
26
Peter.V
202P Gs3 CM25
17 inch LCD Monitor
TYPE : 170S6FG/00
BRAND : PHILIPS
2004-12-15
MODE NO. 567 8
RESOLUTION 640 x 480 640 x 480 640x480 800 x 600
Dot clock(MHz) 31.500 31.501 36 36
f h 37.861kHz37.5kHz36kHz35.2kHz
A (us) 26.413(832 dots) 26.667 (840 dots) 23.111 (832 dots) 28.444(1024 dots)
B (us) 1.270(40 dots) 2.032 ( 54 dots) 1.556 (56 dots) 2.000 ( 72 dots)
C (us) 3.810(120 dots) 3.81 ( 120 dots) 2.222 (80 dots) 3.556 ( 128dots)
D (us) 20.317(640 dots) 20.317 (640 dots) 17.778(640 dots) 22.222(800 dots)
E (us) 1.016(32 dots) 0.508(26 dots) 1.555 (56 dots) 0.666 ( 24 dots)
fv 72.809Hz 75Hz85Hz 56Hz
O(ms) 13.735(520 lines) 13.333(500 lines ) 11.763(509lines ) 17.778(625 lines)
P (ms) 0.079(3 lines) 0.08(3lines ) 0.069 (3lines ) 0.057 ( 2 lines)
Q(ms) 0.528(20 lines) 0.427 ( 16 lines ) 0.578(25 lines ) 0.626 ( 22 lines)
R (ms) 12.678(480 lines) 12.8 (480 lines ) 11.093(480lines ) 17.066 (600 lines)
S (ms) 0.45(17 lines) 0.026 ( 1 lines) 0.023(1 lines) 0.029 ( 1 line)
SYNC. H/V -/- - / - -/- + / +
POLARITY
SEP . SYNC Y Y Y Y
MODE NO. 91011 12
RESOLUTION 800 x 600 800 x 600 800 x 600 800 x 600
Dot clock(MHz) 40 50 49.498 56.251
f h 37.9kHz 48.077kHz 46.9kHz 53.7kHz
A (us) 26.4 (1056 dots) 20.80 (1040dots) 21.333 (1056 dots) 18.631 (1048dots)
B (us) 3.2 ( 128dots) 2.400 ( 120 dots) 1.616 (80 dots) 1.138 ( 64 dots)
C (us) 2.2 (88dots) 1.280 ( 64 dots) 3.232 ( 160 dots) 2.702 ( 152 dots)
D (us) 20 (800 dots) 16.00 (800 dots) 16.162 (800 dots) 14.222 (800 dots)
E (us) 1 ( 40 dots) 1.120 ( 56 dots) 0.323( 16 dots) 0.569 (32 dots)
fv 60Hz 72Hz( 72.188) 75Hz85Hz
O(ms) 16.579(628lines) 13.85 (666 lines) 13.333 (625 lines) 11.756(631 lines)
P (ms) 0.106 ( 4 lines) 0.125 ( 6 lines) 0.064 (3 lines) 0.056 (3 lines)
Q(ms) 0.607 ( 23lines) 0.478(23lines) 0.448(21 lines) 0.503(27 lines)
R (ms) 15.84 (600lines) 12.48(600 lines) 12.8 (600 lines) 11.179 (600 lines)
S (ms) 0.026 ( 1 line) 0.770 (37 line) 0.021 ( 1 line) 0.018(1 lines)
SYNC. H/V+/ ++/ ++/ ++/ +
POLARITY
SEP . SYNC Y Y Y Y
