54
170S6 LCD
General Product Specification
8639 000 16148
2004-12-15
590
12
26
Peter.V
202P Gs3 CM25
17 inch LCD Monitor
TYPE : 170S6FG/00
BRAND : PHILIPS
2004-12-15
MODE NO. 21 22 23 24
RESOLUTION 1152 x864 1152 x870 1152 x 900 1152 x 900
Dot clock(MHz) 108 100 94.5108
f h67.5kHz 68.7kHz 61.8kHz 71.8kHz
A (us) 14.815 (1600 dots) 14.56 (1456 dots) 16.169 (1528dots) 13.926 (1054dots)
B (us) 1.185 ( 128dots) 1.28(128dots) 1.354 ( 128dots) 1.185 ( 128dots)
C (us) 2.37 ( 256 dots) 1.44( 144 dots) 2.201 ( 208dots) 1.778(192 dots)
D (us) 10.667 ( 1152 dots) 11.52 ( 1152 dots) 12.19 ( 1152 dots) 10.667 ( 1152 dots)
E (us) 0.593( 64 dots) 0.32 (32 dots) 0.424 ( 40 dots) 0.296 (32 dots)
fv 75Hz 75Hz 66Hz 76Hz
O(ms) 13.333 (900 lines) 13.333 (916 lines) 15.151 (937lines) 13.132 (943lines)
P (ms) 0.044 (3 lines) 0.044 (3lines) 0.065 ( 4 lines) 0.111 (8 lines)
Q(ms) 0.474 (32 lines) 0.568( 39 lines) 0.501 (31 lines) 0.46 (33 lines)
R (ms) 12.8 (864 lines) 12.678(870 lines) 14.552 (900lines) 12.533 (900 lines)
S (ms) 0.015 ( 1 lines) 0.043(4 line) 0.033 ( 2 line) 0.028(2 lines)
SYNC. H/V -/- -/- Serr- + / +
POLARITY
SEP . SYNC Y Y Y Y
MODE NO. 25 26 27 28
RESOLUTION1280 x 960 1280 x 960 1280 x 1024 1280 x 1024
Dot clock(MHz) 108 129.895 108 117
f h60kHz 75kHz 64kHz 71.7kHz
A (us) 16.667(1800 dots) 13.307 (1728dots) 15.63(1688 dots) 13.949 (1632 dots)
B (us) 1.037(112 dots) 1.047 ( 136 dots) 1.037 ( 112 dots) 0.957 (112 dots)
C (us) 2.889(312 dots) 1.725 ( 224 dots) 2.296 ( 248dots) 1.915 (224 dots)
D (us) 11.852(1280 dots) 9.857 ( 1280 dots) 11.852 ( 1280 dots) 10.94 (1280 dots)
E (us) 0.889(96 dots) 0.678( 88 dots) 0.445 ( 48dots) 0.137 (16 dots)
fv 60Hz 75Hz 60Hz 67Hz
O(ms) 16.667(1000 lines) 13.333 (1002 lines) 16.661 (1066lines) 14.883 (1067lines)
P (ms) 0.05(3 lines) 0.039 (3 lines) 0.047 (3lines) 0.112 (8lines)
Q(ms) 0.600(36 lines) 0.48(36 lines) 0.594 (38 lines) 0.46 (33lines)
R (ms) 16(960 lines) 12.774 (960 lines) 16.005 (1024 ines) 14.283 (1024 lines)
S (ms) 0.017(1 lines) 0.04 (3 lines ) 0.015 ( 1 line) 0.028(2 lines )
SYNC. H/V+/++/ ++/ ++/ +
POLARITY
SEP . SYNC Y Y Y Y
