55
170S6 LCD
General Product Specification
8639 000 16148
2004-12-15
590
13
26
Peter.V
202P Gs3 CM25
17 inch LCD Monitor
TYPE : 170S6FG/00
BRAND : PHILIPS
2004-12-15
MODE NO. 29 30 31 32
RESOLUTION1280 x 1024 1280 x 1024 1280 x 1024 688 x 556
Dot clock(MHz) 130.223 135 138.008 27
Fh 76kHz80kHz81.1kHz 31.25kHz
A (us) 13.158(1712 dots) 12.504(1688 dots) 12.326 (1664 dots) 32 (864 dots)
B (us) 1.024 ( 133 dots) 1.067(144 dots) 0.474 (64 dots) 3.852 (104 dots)
C (us) 1.905 ( 248dots) 1.837(248dots) 2.133 (288 dots) 1.778(48dots)
D (us) 9.83 ( 1280 dots) 9.481(1280 dots) 9.481 (1280 dots) 25.481 (688 dots)
E (us) 0.399( 51 dots) 0.119(16 dots) 0.238(32 dots) 0.889 (24 dots)
F v 72Hz 75Hz 76Hz 50Hz
O(ms) 14 (1064 lines) 13.329(1066 lines) 13.139 (1066 lines) 20 (625 lines)
P (ms) 0.02 ( 2 lines) 0.038(3 lines) 0.099 (8 lines) 0.128(4 lines)
Q(ms) 0.5 ( 38lines) 0.475(38lines) 0.394 ( 32 lines) 1.408(44 lines)
R (ms) 13.468(1024lines) 12.804(1024 lines) 12.622 (1024 lines) 17.972(556 lines)
S (ms) 0.012 ( 0 line) 0.012 (1 line) 0.024( 2 lines ) 0.672 ( 21 lines )
SYNC. H/V+/ ++/+ -/- -/+
POLARITY
SEP . SYNC Y Y Y Y
MODE NO. 33 34
RESOLUTION 960X720 960X720
Dot clock(MHz) 57.58 72.42
Fh 44.76kHz 56.4kHz
A (us) 22.34(1286 dots) 17.73(1284 dots)
B (us) 1.72(99 dots) 1.44(104 dots)
C (us) 2.58(148dots) 2.21(160 dots)
D (us) 16.67(960 dots) 13.256(960 dots)
E (us) 0.856(49 dots) 0.780(56 dots)
F v 60Hz 75Hz
O(ms) 16.667(746 lines) 13.333(752 lines)
P (ms) 0.067(2.9 lines) 0.053(3 lines)
Q(ms) 0.495(22 lines) 0.5(28lines)
R (ms) 16.081(720 lines) 12.766(720 lines)
S (ms) 0.0228(1 lines) 0.0184(1 lines)
SYNC. H/V -/ + -/ +
POLARITY
SEP . SYNC Y Y
