170S6 LCD
General Product Specification
8639 000 16148
2004-12-15
590
14
26
Peter.V
202P Gs3 CM25
17 inch LCD Monitor
TYPE : 170S6FG/00
BRAND : PHILIPS
2004-12-15
A
:H-Total
O
: V-Total
B:H-Sync width P
: V-Sync width
C:H-Backporch Q : V-Backporch
D:H-Video width R : V- Video width
E : H- Front porch S : V- Front porch
3.3.3 Horizontal scanning
Sync polarity. :Positive or Negative
Scanningfrequency. : 30-83 KHz
3.3.4 Vertical scanning
Sync polarity. :Positive or Negative
Scanningfrequency. :56-76Hz
3.4Powerinput connection
Power-cordlength. :1.5M
Power-cord type. : 3 leads p
owercordwith protective earth plug.
3.5Power management
Thepowerconsumption an d thestatus indication of theset with power
management function are as below:
Status H-sync V-sync VideoPowerLED
On On OnActive <35W Green
Stand-by Off OnBlanked <1W
Amber
SuspendOn Off Blanked <1W
Amber
Off Off Off Blanked <1W Amber
DC Poweroff N/A <1 WOff
According to VESA power savingsignal. TCO’03power saving requirement
EPA energy starrequirement
