57
170S6 LCD
General Product Specification
8639 000 16148
2004-12-15
590
15
26
Peter.V
202P Gs3 CM25
17 inch LCD Monitor
TYPE : 170S6FG/00
BRAND : PHILIPS
2004-12-15
3.6Display identification
3.6.1Inaccordancewith VESA Display Channel StandardV1.0 and having DDC-
2B and DDC/CI capability.
4.0 Visual characteristics
4.1Testconditions
Unless otherwise specified, thisspecification is defined u
nderthefollowing
conditions.
(1) Input signal:As defined in 3.3, 1280 x 1024 non-interlaced mode
(80K/75Hz), signal sources musthave 75 ohm outputimpedance.
(2) Luminancesetting:controls to be setto200nitswith full screen70%
duty cycle whitesi
gnal
(3) Warmup: more than 30 minutes after poweronwith signal supplied.
(4) Ambient light: 400 -- 600 lux.
(5) Ambient temperature:20± 5 °C
4.2Resolution
Factorypreset mo des (15 modes)
# Resolution H-Frequency Pixel
rateV-Frequency Comment
1 640X350 31.5KHz 25.175 70Hz IBM VGA 10h
2 720X400 31.5KHz 28.322 70Hz IBM VGA 3h
3 640X480 37.5KHz31.501 75Hz
4 640X4 80 35.0KHz30.24 67Hz
5 640X4 80 31.5KHz 25.175 60Hz
6 800X600 35.2KHz36 56Hz
7 800X600 46.9KHz 49.498 75Hz
8800X600 37.9KH z 40 60Hz
9 832X624 49.7KHz 57.28 75Hz MAC
10 1024X768 60.0KHz 78.75 75Hz
11 1024X768 48.4KHz 65 60Hz
12 1152X870 68.7KHz 100 75Hz MAC
13 1152X900 71.8KHz 108 76Hz SUNMode II
14 1280X1024 64.0KHz 108 60Hz
15 1280X1024 80.0KH z 135 75Hz
Note:1. Screen displays perfect pictureat15factory-preset modes.
2. Screen displays visible picturewith OSD warningwheninput modes are
otherthen 34 preset modes
