58
170S6 LCD
General Product Specification
8639 000 16148
2004-12-15
590
16
26
Peter.V
202P Gs3 CM25
17 inch LCD Monitor
TYPE : 170S6FG/00
BRAND : PHILIPS
2004-12-15
4.3 Brightness: 200 nits(at panel color temperature, Screencenter point, Fig. 1)
4.4Image size
4.4.1 Actual d isplay size :338x270mm
4.5Brightness uniformity
Setcontrast at50%and turn thebrightness to get average above 200 nitsat
centerof thescreen.
Apply the Fi
g 1. It should comply with thefollowingformula:
Minimum luminance of ninepoints(brightness)
>= 0.75 (Min)
Maximum luminance of ninepoints(brightness)
4.6Check Cross talk (S)
Apply Pattern 2. Set contrast at50%andbrightness at 100 %. Measure
A.
ThenoutputPattern 3andmeasure A’. The cross talk value:
ABS ( A-A’)
¾¾¾¾¾¾¾¾¾ X 100 %<1.5 %(Max)
A
