GENERAL PRODUCT SPECIFICATION(Continued)
1 FOREWORD
Thisspecification describesa19"WWXGA+multi-scan color TFT LCD monitorwithmax.resolution up to
1440*900/76
75Hz non-interlaced.
All optical characteristics (includingWHITE-D, Bri ghtness, and so on) are determined according to panel
specification afterwarming up approximate 30 minutes that brightness stability is optimal, and followstrictly af
ter
panelspecification.
2 PRODUCTPROFILE
This display monitor unit isacolor display monitor enclosed in PHILIPS global stylingcabinet which has an
integrated tilt base.
2.1 LCD
2.1.1 TypeNR. : M190A1
Outside dimensions : 427.2(w)*277.4(h)*17.0(d) (Typ) mm
Pitch
( mm ) : 0.285 mm x 0.285 mm
Colorpixel arrangement : RGBvertical stripes
Display surface :lowreflection,antiglare with hard coating
Color depth:16.2Mcolors (6 bits+FRC)
Backlight :CCFL edge light system
Active
area(WxH) : 410.4 x 256.5mm (19.05" diagonal)
Viewangle(CR>10) : 75/75 (min), 85/85 (typ) forHorizontal & 70/70 (min), 80/80 (typ) forVertical
Contrast ratio : 850:1(Typ.) 500:1(Min.)
White luminance : Original color 230 nits (Min), 300 nits (T
yp.)
Gate IC:
SourceIC:
Responsetime :5ms(typ)
2.2 Scanningfrequencies
Hor. : 30 - 83 K Hz
Ver. : 55 -75Hz
Video dot rate : <140 MHz
Power input : 90-264 V AC, 50/60 ± 2Hz
Powerconsumption :<36W(typ.) maximum
2.3 Ambient temperature :0°C-35°C
3 Electrical characteristi cs
3.1 Interface signals
1).D-Sub Analog
Input signal : Video,Hsync., Vsync
Video :0.7Vp-p,input impedance,75ohm @DC
Sync. : Separate sync TTLlevel,input impedanc
e 2.2k ohm terminate
Hsync Positive/Negative
Vsync Positive/Negative
Composite sync TTLlevel, input impedance 2.2k ohm terminate (Positive/Negative)
Sync on green video 0.3 Vp-p Negative(Video 0.7 Vp-p Positiv
e)
