GENERAL PRODUCT SPECIFICATION(Continued)
MODENO.21 22 23 24
RESOLUTION 1152 x 864 1152 x 870 1152 x 900 1152 x 900
Dot clock(MHz) 108 100 94.5 108
f h 67.5kHz 68.7kHz 61.8kHz 71.8kHz
A(us ) 14.815 (1600 dots) 14.56 (1456 dots) 16.169 (1528 dots) 13.926 (1054dots)
B (us ) 1.185 ( 128 dots) 1.28 ( 128 dots) 1.354 ( 128 dots) 1.185 ( 128 dots)
C (us ) 2.37 ( 256 dots) 1.44( 144 dots) 2.201 ( 208 dots) 1.778 ( 192 dots)
D (us ) 10.667 ( 1152 dots) 11.52 ( 1152 dots) 12.19 ( 1152 dots) 10.667 ( 1152 dots)
E(us ) 0.593 ( 64 dots) 0.32 ( 32 dots) 0.424 ( 40 dots) 0.296 ( 32 dots)
f v 75Hz 75Hz 66Hz 76Hz
O(ms ) 13.333 (900 lines) 13.333 (916 lines) 15.151 (937lines) 13.132 (943 lines)
P(ms ) 0.044 ( 3lines) 0.044 ( 3lines) 0.065 ( 4lines) 0.111 ( 8lines)
Q (ms ) 0.474 ( 32 lines) 0.568( 39 lines) 0.501 ( 31 lines) 0.46 ( 33 lines)
R(ms ) 12.8 (864 lines) 12.678 (870 lines) 14.552 (900lines) 12.533 (900 lines)
S(ms ) 0.015 ( 1lines) 0.043 ( 4line ) 0.033 ( 2line ) 0.028 ( 2lines)
SYNC. H/V - / - - / - Serr- + / +
POLARITY
SEP . SYNCY Y Y Y
MODENO.25 26 27 28
RESOLUTION 1280 x 960 1280 x 960 1280 x 1024 1280 x 1024
Dot clock(MHz) 108 129.895 108 117
f h 60kHz 75kHz 64kHz 71.7kHz
A(us ) 16.667(1800 dots) 13.307 (1728 dots) 15.63 (1688 dots) 13.949 (1632 dots)
B (us ) 1.037(112 dots) 1.047 ( 136 dots) 1.037 ( 112 dots) 0.957 (112 dots)
C (us ) 2.889(312 dots) 1.725 ( 224 dots) 2.296 ( 248 dots) 1.915 (224 dots)
D (us ) 11.852(1280 dots) 9.857 ( 1280 dots) 11.852 ( 1280 dots) 10.94 (1280 dots)
E(us ) 0.889(96 dots) 0.678 ( 88 dots) 0.445 ( 48 dots) 0.137 (16 dots)
f v 60Hz 75Hz 60Hz 67Hz
O(ms ) 16.667(1000 lines) 13.333 (1002 lines) 16.661 (1066 lines) 14.883 (1067lines)
P(ms ) 0.05(3lines) 0.039 ( 3lines) 0.047 ( 3lines) 0.112 ( 8lines)
Q (ms ) 0.600(36 lines) 0.48 ( 36 lines) 0.594 ( 38 lines) 0.46 ( 33 lines)
R(ms ) 16(960 lines) 12.774 (960 lines) 16.005 (1024 lines) 14.283 (1024 lines)
S(ms ) 0.017(1lines) 0.04 ( 3lines ) 0.015 ( 1line) 0.028 (2lines )
SYNC. H/V +/+ + / + + / + + / +
POLARITY
SEP . SYNCY Y Y Y
MODENO.29 30 31 32
RESOLUTION 1280 x 1024 1280 x 1024 1280 x 1024 1360 x 768
Dot clock(MHz) 130.223 135 138.008 85.5
F h 76kHz 80kHz 81.1kHz 47.712kHz
A(us ) 13.158 (1712 dots) 12.504(1688 dots) 12.326 (1664 dots) 20.959(1792 dots)
B (us ) 1.024 ( 133 dots) 1.067(144 dots) 0.474 (64 dots) 1.31(112 dots)
C (us ) 1.905 ( 248 dots) 1.837(248 dots) 2.133 (288 dots) 2.994(256 dots)
D (us ) 9.83 ( 1280 dots) 9.481(1280 dots) 9.481 (1280 dots) 15.906(1360 dots)
E(us ) 0.399( 51 dots) 0.119(16 dots) 0.238 (32 dots) 0.749(64 dots)
F v 72Hz 75Hz 76Hz 60.015Hz
O(ms ) 14 (1064 lines) 13.329(1066 lines) 13.139 (1066 lines) 16.662(795 lines)
P(ms ) 0.02 ( 2lines) 0.038(3lines) 0.099 ( 8lines) 0.126(6lines)
Q (ms ) 0.5 ( 38 lines) 0.475(38 lines) 0.394 ( 32 lines) 0.377(18 lines)
R(ms ) 13.468 (1024 lines) 12.804(1024 lines) 12.622 (1024 lines) 16.097(768 lines)
S(ms ) 0.012 ( 0line) 0.012 (1line) 0.024( 2lines ) 0.063(3lines)
SYNC. H/V + / + +/+ - / - + / +
POLARITY
SEP . SYNCY Y Y Y
8639 000 17256
2006-06-22
2006-06-22
590
BRAND:PHILIPS
19 inch TFT WXGA LCD Monitor
TYPE : 190CW7CS/00
