190CW7 LCD
22
13
GENERAL PRODUCT SPECIFICATION(Continued)
MODE NO. 33 34 35 36
RESOLUTION 1440 x 900 1440 x 900 1280x720 1280x720
Dot clock(MHz) 106.50 136.75 74.5 89.04
F h 55.935kHz 70.635kHz 44.772KHz 52.5KHz
A ( us ) 17.878(1904 dots) 14.157(1936 dots) 22.335 19.048
B ( us ) 1.427(152 dots) 1.112(152 dots) 1.718 1.527
C ( us ) 2.718(232 dots) 1.814(248 dots) 2.577 2.336
D ( us ) 13.521(1440 dots) 10.53(1440 dots) 17.181 14.376
E ( us ) 0.751(80 dots) 0.702(96 dots) 0.859 0.809
F v 59.887Hz 74.984Hz 59.855 70
O (ms ) 16.698(934 lines) 13.336(942 lines) 16.707 14.286
P ( ms ) 0.107(6 lines) 0.085(6 lines) 0.112 0.057
Q (ms ) 0.447(25 lines) 0.467(33 lines) 0.447 0.495
R ( ms ) 16.09(900 lines) 12.741(900 lines) 16.082 13.714
S ( ms ) 0.054(3 lines) 0.042(3 lines) 0.067 0.019
SYNC.H/V -/+ -/+ -/+ -/+
POLARITY
SEP . SYNC Y Y YY
MODE NO. 37 38 39 40
RESOLUTION 1280x720 1280 x 768 1280 x 768 1280 x 768
Dot clock(MHz) 95.75 79.5 94.976 102.25
Fh 56.456KHz 47.776kHz 56kHz 60.289kHz
A(us) 17.713 20.931 17.857 16.587
B(us) 1.337 1.61 1.432 1.252
C(us) 2.172 2.415 2.19 2.034
D(us) 13.368 16.101 13.477 12.518
E(us) 0.836 0.805 0.758 0.782
Fv 74.777 59.87Hz 70Hz 74.893Hz
O(ms) 13.373 16.703 14.286 13.352
P(ms) 0.089 0.147 0.054 0.116
Q(ms) 0.478 0.419 0.5 0.448
R(ms) 12.753 16.075 13.714 12.739
S(ms) 0.053 0.063 0.018 0.05
SYNC. H/V -/+ - / + -/+ -/ +
POLARITY
SEP . SYNC YYY Y
BRAND : PHILIPS
19 inch TFT WXGA LCD Monitor
TYPE : 190CW7CS/00
8639 000 17256
2006-06-22
2006-06-22
590
