HUDSON 8
17
73
BRIGHT DOT DEFECTS ACCEPTABLE LEVEL
MODEL
190CW8
1 lit sub-pixel 3
2 adjacent lit sub-pixels 1
3 adjacent lit sub-pixels (one white p ixel) 0
Distance between two bright dot defects*
25mm
Bright dot defects within 20 mm circle 0
Total bright dot defects of all type 3
BLACK DOT DEFECTS ACCEPTABLE LEVEL
MODEL
190CW8
1 dark sub-pixel 5
2 adjacent dark sub-pixels 2
3 adjacent dark sub-pixels (one white pixel) 0
Distance between two black dot defects*
15mm
Black dot defects within 20 mm circle* 1
Total black dot defects of all type 5
TOTAL DOT DEFECTS ACCEPTABLE LEVEL
MODEL
190CW8
Total bright or black dot defects of all type 5
* 1 or 2 adjacent sub-pixel defects = 1 dot defect
Fig 1: Brightness and Uniformity
1
2
3
7
8
W/10
L
W
L/10
L/2
W/2
456
9
Position 5 = Screen center point
BRAND : PHILIPS
19 inch LCD Monitor
TYPE :190CW8
2007-08-01
590
2007-08-01
GENERAL PRODUCT SPECIFICATION(Continued)
