18 220BL2 LCD
(OHFWULFDO,QVWUXFWLRQV
White color adjustment
There are three factory preset white color 9300K, 6500K, sRGB.
Apply full gray64 pattern, with brightness in 100 % position and the contrast control at 50 % position.
The 1931 CIE Chromaticity (color triangle) diagram (x ,y) coordinate for the screen center should be:
Product specification
CIE coordinates (x,y)
11500K x = 0.270 ± 0.02
y = 0.281 ± 0.02
FGA
9300K x = 0.283 ± 0.02
y = 0.297 ± 0.02
8200K x = 0.291 ± 0.02
y = 0.306 ± 0.02
FGA
7500K x = 0.298 ± 0.02
y = 0.314 ± 0.02
FGA
6500K/sRGB x = 0.313 ± 0.02
y = 0.329 ± 0.02
sRGB x = 0.313 ± 0.02
y = 0.329 ± 0.02
5000K x = 0.345 ± 0.02
y = 0.357 ± 0.02
FGA
Production alignment spec.
CIE coordinates (x,y)
11500K x = 0.270 ± 0.006
y = 0.281 ± 0.006
FGA
9300K x = 0.283 ± 0.006
y = 0.297 ± 0.006
8200K x = 0.291 ± 0.006
y = 0.306 ± 0.006
FGA
7500K x = 0.298 ± 0.006
y = 0.314 ± 0.006
FGA
6500K/sRGB x = 0.313 ± 0.006
y = 0.329 ± 0.006
sRGB x = 0.313 ± 0.006
y = 0.329 ± 0.006
5000K x = 0.345 ± 0.006
y = 0.357 ± 0.006
FGA
Quality Inspection specification:
CIE coordinates (x,y)
9300K x = 0.283 ± 0.015
y = 0.297 ± 0.015
6500K/sRGB x = 0.313 ± 0.015
y = 0.329 ± 0.015
sRGB x = 0.313 ± 0.015
y = 0.329 ± 0.015
