16. Recommended & Spare Parts List
Note: Take the 223V5LSB2/93 (TPV) BOM for example, the parts information listed below are for reference only,
and are subject to change without notice. Please go to http://cs.tpv.com.cn/hello1.asp for the latest information
Item
Location
PCM Codes
Description
Remark
WH205
705GHDCS044003
EPS ASS'Y
WH202
H44GB06681301A00HX
ARTWORK CARTON 223V5 CH
WH209
Q45G990161940800BX
PROTECT BAG
ECN401
S95G179T30PW23
FFC CABLE 30P 190mm 1.0MM
2nd source
E08902
389G0722CAA02G
D-SUB CABLE 1200
2nd source
E08902
389G0722HAA02G
D-SUB CABLE 1200
E08901
389G414A12N0HL
AC POWER CORD 1200 for China
E08901
389G414A12N0IS
AC POWER CORD 1200
2nd source
ECN401
395G179X30PW23
FFC CABLE 30P 190mm 1.0MM
E750
750GBV215GE3D6N000
LCD TPM215HW01-HGEL03 C1D WH TPV
WH201
H40G000N81302A
RATING LABEL V5 CH NO TCO
WH206
H41G78S181321A
QSG 223V5 M5223VQ1CHT CHINA
WH208
H70G21C181303A
CD MANUAL 223V5 M5223V1T
WH110
Q15G142920110100B1
MAINFRAME
WH109
A34G3266DBK01K0100
STAND
WH108
Q34B77435190007W33
Plastic front frame ABS+HB
WH107
Q34G7744DBK02K0130
REAR_COVER
WH111
Q34G7745DBK01K0130
BASE
M037
H37G00390110CX
HINGE ASS'Y
WH418
Q12G630017600A00SI
FOOT PAD
2nd source
WH002
CBPCDUAPHH1
SCALER BOARD
WH002
756GHDCB0PB005010H
SCALER BOARD ASSY(CBPCDUAPHH1)
2nd source
SMTCD-U402
100GPMVI001W11
MCU ASSY-056G2233 37
CN701
033G3802 6B Y
CONN 6PIN 2.0
CN403
033G3802 7B Y
WAFER
X401
093G 22 53CEC
CRYSTAL S-F-14.31818M-32-3030-2085-30
CN401
311GF100B30ABL
FFC CONN 1.0mm 30P R/A B1002F30TDHB
CN101
388G353HE01AXH
D-SUB R/A 15P 1*1 BLUE --
C401
067G 3051013PB
EC 105C 100uF M 16V 5*11mm JH CD263
U701
056G 563527BHF
LDO BL1117-33CX 1A 3.3V SOT-223
U103
056G1133161
EEPROM AT24C02C-SSHM-T 2Kb SOIC-8
2nd source
U402
056G2233 37
MX25L4006EM1I-12G 4Mb SOP-8 150 mil
Q402
057G 417517
Tra LMBT3906LT1G -200mA/-40V SOT-23 LRC
Q701
057G 417518
TRA LMBT3904LT1G 200mA/40V SOT-23 LRC
Q702
057G 763940
MOSFET AO3401A SOT-23
R430
061G0402000 JT
RST 0402 0.05R MAX 1/16W -
2nd source
R430
061G0402000 JY
RST CHIPR MAX 0R05 OHM 1/16W YAGEO
R105
061G0402100 JT
RST CHIP 10R 1/16W 5% TZAI YUAN
2nd source
R107
061G0402100 JY
RST CHIPR 10 OHM +-5% 1/16W YAGEO
R115
061G0402101 JT
RST CHIP 100R 1/16W 5% TZAI YUAN
2nd source
R121
061G0402101 JY
RST CHIPR 100 OHM +-5% 1/16W YAGEO
R421
061G0402102 JT
RST CHIP 1K 1/16W 5% TZAI YUAN
2nd source
R103
061G0402102 JY
RST CHIPR 1KOHM +-5% 1/16W YAGEO
R706
061G0402103 JT
RST CHIP 10K 1/16W 5% TZAI YUAN
2nd source
R402
061G0402103 JY
RST CHIPR 10KOHM +-5% 1/16W YAGEO
R423
061G0402104 JT
RST CHIP 100K 1/16W 5% TZAI YUAN
2nd source
R707
061G0402104 JY
RST CHIPR 100KOHM +-5% 1/16W YAGEO
R117
061G0402222 JT
RST CHIP 2K2 1/16W 5% TZAI YUAN
2nd source
R116
061G0402222 JY
RST 0402 2.2K 5% 1/16W RC0402JR-072K2L
