Pin Assignment:
Pin
Signal Assignment
Pin
Signal Assignment
1
T.M.D.S. data2-
13
No Connect
2
T.M.D.S. data2+
14
+5V Power
3
T.M.D.S. data2 shield
15
Ground (for +5V)
4
No Connect
16
Hot plug detect
5
No Connect
17
T.M.D.S. data0-
6
DDC clock
18
T.M.D.S. data0+
7
DDC data
19
T.M.D.S. data0 shield
8
No Connect
20
No Connect
9
T.M.D.S. data1-
21
No Connect
10
T.M.D.S. data1+
22
T.M.D.S clock shield
11
T.M.D.S. data1 shield
23
T.M.D.S. clock+
12
No Connect
24
T.M.D.S. clock-
3.2.3 DisplayPort cable (option)
Length : Please refer to cable bundle summary file
Connector type : DisplayPort 1.1 External cable-connector
Pin Assignment:
Pin No.
Description
Pin No.
Description
1
Lane 0 (positive)
11
Ground
2
Ground
12
Lane 3 (negative)
3
Lane 0 (negative)
13
connected to Ground
4
Lane 1 (positive)
14
connected to Ground
5
Ground
15
Auxiliary Channel (positive)
6
Lane 1 (negative)
16
Ground
7
Lane 2 (positive)
17
Auxiliary Channel (negative)
8
Ground
18
Hot Plug Detect
9
Lane 2 (negative)
19
Return for Power
10
Lane 3 (positive)
20
Power for connector
3.2.4 HDMI cable(option)
Length : Please refer to cable bundle summary file
Connector type : HDMI 1.4 type A cable-connector
Pin Assignment:
Pin No.
Description
Pin No.
Description
1
TMDS Data2+
11
TMDS Clock Shield
2
TMDS Data2 Shield
12
TMDS Clock–
3
TMDS Data2–
13
CEC
4
TMDS Data1+
14
Reserved (HDMI 1.0-1.3c), HEC Data-
(Optional, HDMI 1.4+ with Ethernet)
5
TMDS Data1 Shield
15
SCL (I²C Serial Clock for DDC)
6
TMDS Data1–
16
SDA (I²C Serial Data Line for DDC)
7
TMDS Data0+
17
DDC/CEC/HEC Ground
8
TMDS Data0 Shield
18
+5 V Power (max 50 mA)
9
TMDS Data0–
19
Hot Plug Detect (All versions) and HEC
Data+ (Optional, HDMI 1.4+ with
Ethernet)
10
TMDS Clock+
