0.1 M4 241S4 / 241B4 24” Wide 16:9 LCD Monitor
2011/07/12 PHILIPS 9 of 20
241B4LP LCD 5
ʳ
3.2 Timing requirement
Factory Preset mode definition:
1. Perfect FOS while presenting those timings.
2. Will specify those timing in User's Manual
Preset mode definition:
1. Need to support those timings.
2. Perfect FOS after auto adjustment.
User mode
1. Can save those timing that not in Preset mode and can be showed (not over scaler or
Panel spec.)
2. It needs to reserve the 10 timings space in memory size.
3.2.1 Mode storing capacity
Factory preset modes : Refer to Timing table
preset modes : Refer to Timing table
User modes : Refer to Timing table
Timing pixel clock over H/W limitation do not support.
1. Factory preset modes and preset modes are defined in the enclosed timing table file
