0.1 M4 241S4 / 241B4 24” Wide 16:9 LCD Monitor
2011/07/12 PHILIPS 15 of 20
241B4LP LCD 71
ʳ
5.9 If paint is used
x RoHS required
x WEEE require
x If new painting type need to implement, refer to UN-D 1235.
5.10 Plastic mold tooling
x Tooling to be designed to minimize cosmetic defects induced by molding process (sink, blush,
weld lines, gate marks, ejector marks, etc.). Refer to “TYV61-90007”.
x Painting to cover up cosmetic defects due to molding is strongly discouraged.
x China RoHS mark requested.
5.11 Plastics flammability
x All Plastics to be Flame Retardant UL 94-HB or Better.
x Base / Pedestal to be Flame Retardant UL 94-HB.
x All major plastic parts (bezel, back cover) need to be molded from same resin.
x Plastic resin type selection should be referred to “plastic-Philips Pool monitor”.
5.12 Texture/Glossing of housing
x The texture area and texture no should follow Philips make-up sheet.
x The exterior surfaces shall have a uniform texture.
x Philips must approve the mold texturing.
x Detail document for texture refer to “UN-D249”, “UN-D 600”.
x Glossy surface > = 80 gloss units
5.13 Tilt and swivel base
x Tilt angle : -5 q +2/- 0 q (forward)
+20 q+ 0/- 3 q (backward)
x Swivel angle : nil
x High Adjustment : nil
x Portrait Display : nil
5.14 Kensington Lock
x Must meet Kensington_slot.spec “TYE-M0004”.
x MMD request metal plate in Kensington hole.
