16. Recommended & Spare Parts List
Recommended Parts List for 273E3LHSB/00
Item Location PCM Codes Description Remark
1 FQ106 A34G2413BPDE1B0130 BEZEL L27W-TS30-tss10
2 FQ125 A33G1193BDY 3L0100 DECO BEZEL-L
3 FQ125 A33G1192BDY 3L0100 DECO BEZEL-R
4 FQ004 KEPCAQP6 KEY BOARD ASSY
5 E750 750GBM270GEA22M0PH LCD M270HGE-L10 C2 NB CMI
5 E750 750GBM270GEA22N000 LCD M270HGE-L10 C2 NB CMI
6 FQ010 ADPCA1603QXB ADAPTER BOARD ASSY
7 FQ002 756GQACB PH127 00 SCALER BOARD ASSY(CBPCANUPHQH)
8 E07801 078G 500 2A K SPK 4 OHM 2.5W 57.5X34 360 260mm KUAIDA
9 FQ124 A15G0887C0120A MAIN_FRAME
10 FQ105 A34G1480AFLAVB0100 REAR COVER L27W-TS30-tss10
11 FQ110 A37G0135 1 HINGE
12 FQ126 A34G1481AFL 1B0100 STAND
13 FQ109 A34G2414BPD 1B0133 BASE L27W-TS30-tss10
FQ305 089G 17356G553 AUDIO CABLE 1800MM
E08902 089G 725CAA 2G D-SUB CABLE 1500MM
E08907 089G179J30NA08 FFC CABLE 30PIN 182MM P1.0MM
FQ301 089G404A15N IS AC POWER CORD 1500
FQ205 803GQA44069 L27W-TS30-tss10 273E3 EPS ASSY
FQ202 Q44GF015813 5A 27 LCD CARTON
FQ212 Q45G 88609196 EPE BAG
FQ210 Q45G9901609231 P.E. BAGX430X300X0.5
FQ133 A85G0206101 MAINFRAME SHIELDING
U402 100GPNMG001NT1 MCU ASSY(056G2233 11)
X401 093G 2251B J CRYSTAL 12MHZ NXS12.000AC30F-KAB10
U401 056G 562392 SCALER NT68677UMFG/E QFP-128
U703 056G 563206 IC LDO AP2114H-1.8TRG1 1A/1.8V SOT-223
U701 056G 563224 IC LDO AP2114H-3.3TRG1 1A/3.3V SOT-223
U601 056G 616110 AUDIO PAM8007NHR 3W SSOP-24
U501 056G 662 18 ESD PROTECT AZ1045-04F.R7G DFN2510P10E
U502 056G 662 18 ESD PROTECT AZ1045-04F.R7G DFN2510P10E
U105 056G 662502 IC ESD AZC199-04S.R7G SOT23-6L
U106 056G 662502 IC ESD AZC199-04S.R7G SOT23-6L
