7
Meridian 3
Note:
1. EPEAT Gold or Silver is valid only where Philips registers the product. Please visit www.epeat.net
for
registration status in your country.
2. This data is subject to change without notice. Go to www.philips.com/support
to download the latest
version of leaflet.
3. This monitor is brominates flame retardant and polyvinyl chloride-free (PVC/BFR free) for all user
accessible parts (excluding cables and adaptors). Organ bromine compounds in the form of flame
retardants must not be used in those portions equal to or greater than 0.09% (900ppm maximum of
Bromine) and organ bromine compounds in the form of polyvinyl chloride or polyvinyl chloride congeners
must not be used in those portions equal to or greater than 0.1% (1000ppm maximum of chlorine).
2. LCD Monitor Description
The LCD monitor will contain a scaler board, a power board and a key board. The scaler board houses the flat
panel control logic, brightness control logic and DDC.
The power board will provide AC to DC inverter voltage to drive the backlight of panel and the scaler board chips
each voltage.
Adapter Board
Monitor Block Diagram
DC 14.5V
Converter Board
LED Panel
Scaler Board
(Include: Audio)
HDMI
DVI-D
D-SUB
LED Drive
Video signal, DDC
Key Board
HOST Computer
AC IN
90 ~ 264 V
To Next Page
