70
Meridian 3
6 DDC clock 18 T.M.D.S. data0+
7 DDC data 19 T.M.D.S. data0 shield
8 No Connect 20 No Connect
9 T.M.D.S. data1- 21 No Connect
10 T.M.D.S. data1+ 22 T.M.D.S clock shield
11 T.M.D.S. data1 shield 23 T.M.D.S. clock+
12 No Connect 24 T.M.D.S. clock-
3.2.3 HDMI Cable
The input signals are applied to the display through HDMI cable.
Length : 1.8 M +/- 50 mm
Connector type : HDMI male with DDC-2B pin assignments
White connector thumb-operated jackscrews with transplant pin protective cover.
Pin Assignment:
Pin Signal Assignment Pin Signal Assignment
1 TMDS data 2+ 11 TMDS data c Shield
2 TMDS data 2 Shield 12 TMDS data ck-
3 TMDS data 2- 13 CEC
4 TMDS data 1+ 14 N.C
5 TMDS data 1 Shield 15 DDC SCL
6 TMDS data 1- 16 DDC CLK
7 TMDS data 0+ 17 DDC/CEC Ground
8 TMDS data 0 Shield 18 +5 V Power
9 TMDS data 0- 19 Hot Plug Detect
10 TMDS data ck+
1.3 Timing Requirement
Factory Preset Mode Definition:
a. Perfect FOS while presenting those timings.
b. Will specify those timing in User's Manual
Preset Mode Definition
a. Need to support those timings
b. Perfect FOS after auto adjustment.
User Mode
a. Can save those timing that not in Preset mode and can be showed (not over scaler or Panel spec.)
b. It needs to reserve the 10 timings space in memory size.
3.3.1 Mode Storing Capacity
Factory preset modes : 15
User modes : 41
User modes : 10
