9
2.3 Remove the Base Assembly
for VESA Mounting
Before you start disassembling the
monitor base, please follow the
instructions below to avoid any possible
damage or injury.
1. Place the monitor face down on a
smooth surface. Pay attention not to
scratch or damage the screen. Then
lift the monitor stand.
2. While keeping the release button
pressed, tilt the base and slide it out.
Note
This monitor accepts a 100mm x 100mm
VESA-Compliant mounting interface.
VESA Mounting Screw M4. Always
contact manufacturer for wall-mount
installation.
100mm
100mm
-5°
90°
* Display design may dier from those
illustrated.
Warning
To avoid potential screen damage,
such as panel peeling, ensure that
the monitor does not tilt downward
by more than -5 degrees.
Do not press the screen while
adjusting the angle of the monitor.
Grasp only the bezel.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Philips 27M1C5500VL and is the answer not in the manual?

Philips 27M1C5500VL Specifications

General IconGeneral
Haze rate25 %
Panel typeVA
Color depth8 bit
Pixel pitch0.2331 x 0.2331 mm
Pixel density108.79 ppi
Backlight typeW-LED
Display diagonal27 \
Surface hardness3H
Anti-glare screenYes
Display technologyLCD
Native aspect ratio16:9
Vertical scan range48 - 165 Hz
Response time (fast)1 ms
Horizontal scan range30 - 250 kHz
NTSC coverage (typical)95.6 %
Screen curvature rating1500R
Viewable size, vertical335.664 mm
sRGB coverage (typical)126.5 %
Contrast ratio (typical)4000:1
Display number of colors16.7 million colors
Display diagonal (metric)68.5 cm
Viewable size, horizontal596.736 mm
Display brightness (typical)250 cd/m²
Supported graphics resolutions2560 x 1440
High Dynamic Range (HDR) technologyHigh Dynamic Range 10 (HDR10)
Dynamic contrast ratio marketing nameMega Infinity DCR
Picture enhancementSmartImage game
Exterior finish typeTextured
Regulatory ApprovalsCB; CE Mark; FCC Class B; ICES-003; CU-EAC; EAEU RoHS; TUV/ISO9241-307; TUV-BAUART
Recyclable packaging material100 %
Mean time between failures (MTBF)50000 h
Component video syncSeparate sync
HDCP version1.4/2.2
Headphone out-
DisplayPort version1.4
LED indicatorsOperation, Stand-by
Tilt angle range-5 - 20 °
Cable lock slot typeKensington
Panel mounting interface100 x 100 mm
On Screen Display (OSD) languagesCHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR, UKR
AC input voltage100 - 240 V
Power supply typeInternal
AC input frequency50 - 60 Hz
Power consumption (off)0.3 W
Power consumption (standby)0.5 W
Power consumption (typical)38.7 W
Doesn't containMercury (element), PVC/BFR
Sustainability certificatesRoHS
Cables includedHDMI, DisplayPort, AC
Package depth226 mm
Package width730 mm
Package height469 mm
Package weight9200 g
Product colorBlack
Market positioningGaming
Operating altitude0 - 3658 m
Non-operating altitude0 - 12192 m
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)20 - 80 %
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)193 mm
Width (with stand)611 mm
Height (with stand)447 mm
Weight (with stand)5490 g
Depth (without stand)83 mm
Height (without stand)366 mm
Weight (without stand)4180 g
