Philips 27M1C5500VL User Manual

19
7. Power Management
If you have VESA DPM compliance display
card or software installed in your PC, the
monitor can automatically reduce its
power consumption when not in use. If
an input from a keyboard, mouse or other
input device is detected, the monitor will
'wake up' automatically. The following
table shows the power consumption and
signaling of this automatic power saving
feature:
Power Management Denition
VESA Mode Video H-sync V-sync
Power
Used
LED
Color
Active ON Yes Yes
38.7 W
(typ.)
59.8 W
(max.)
White
Sleep
(Standby
mode)
OFF No No 0.5 W
White
(blink)
O mode OFF - - 0.3 W OFF
The following setup is used to measure
power consumption on this monitor.
• Native resolution: 2560 x 1440
• Contrast: 50%
• Brightness: 60%
• Color temperature: 6500k with full
white pattern
Note
This data is subject to change without
notice.

Philips 27M1C5500VL Specifications

General

Haze rate	25 %
Panel type	VA
Color depth	8 bit
Pixel pitch	0.2331 x 0.2331 mm
Pixel density	108.79 ppi
Backlight type	W-LED
Display diagonal	27 \
Surface hardness	3H
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	48 - 165 Hz
Response time (fast)	1 ms
Horizontal scan range	30 - 250 kHz
NTSC coverage (typical)	95.6 %
Screen curvature rating	1500R
Viewable size, vertical	335.664 mm
sRGB coverage (typical)	126.5 %
Contrast ratio (typical)	4000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	68.5 cm
Viewable size, horizontal	596.736 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	2560 x 1440
High Dynamic Range (HDR) technology	High Dynamic Range 10 (HDR10)
Dynamic contrast ratio marketing name	Mega Infinity DCR
Picture enhancement	SmartImage game
Exterior finish type	Textured
Regulatory Approvals	CB; CE Mark; FCC Class B; ICES-003; CU-EAC; EAEU RoHS; TUV/ISO9241-307; TUV-BAUART
Recyclable packaging material	100 %
Mean time between failures (MTBF)	50000 h
Component video sync	Separate sync
HDCP version	1.4/2.2
Headphone out	-
DisplayPort version	1.4
LED indicators	Operation, Stand-by
Tilt angle range	-5 - 20 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR, UKR
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	38.7 W
Doesn't contain	Mercury (element), PVC/BFR
Sustainability certificates	RoHS
Cables included	HDMI, DisplayPort, AC
Package depth	226 mm
Package width	730 mm
Package height	469 mm
Package weight	9200 g
Product color	Black
Market positioning	Gaming
Operating altitude	0 - 3658 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth (with stand)	193 mm
Width (with stand)	611 mm
Height (with stand)	447 mm
Weight (with stand)	5490 g
Depth (without stand)	83 mm
Height (without stand)	366 mm
Weight (without stand)	4180 g
