Philips 27M1C5500VL User Manual

10
3. Image Optimization
3.1 SmartImage
1
What is it?
SmartImage provides presets that
optimize display for dierent types
of content, dynamically adjusting
brightness, contrast, color and sharpness
in real time. Whether you're working
with text applications, displaying images
or watching a video, Philips SmartImage
delivers great optimized monitor
performance.
2
Why do I need it?
You want a monitor that delivers
optimized display all your favorite
types of content, SmartImage software
dynamically adjust brightness, contrast,
color and sharpness in real time
to enhance your monitor viewing
experience.
3
How does it work?
SmartImage is an exclusive, leading edge
Philips technology that analyzes the
content displayed on your screen. Based
on a scenario you select, SmartImage
dynamically enhances the contrast, color
saturation and sharpness of images to
enhance the contents being displayed -
all in real time with the press of a single
button.
4
How to enable SmartImage?
1. Toggle to the left to launch the
SmartImage on screen display.
2. Toggle to the up or down to select
between the smartImage modes.
3. The SmartImage on screen display
will remain on screen for 5 seconds,
or you can also toggle to the left to
make conrmation.
There are multiple selections: FPS,
Racing, RTS, Gamer 1, Gamer 2, LowBlue
Mode, EasyRead and O.


 

 

 



• FPS: For playing FPS (First Person
Shooters) games. Improves dark
theme black level details.
• Racing: For playing Racing games.
Provides fastest response time and
high color saturation.
• RTS: For playing RTS (Real Time
Strategy) games, a user-selected
portion can be highlighted for RTS
games (through SmartFrame). The
picture quality can be adjusted for
the highlighted portion.
• Gamer 1: User’s preference settings
saved as Gamer 1.
• Gamer 2: User’s preference settings
saved as Gamer 2.
• LowBlue Mode: LowBlue Mode for
easy on-the-eyes productivity Studies
have shown that just as ultra-
violet rays can cause eye damage,

Philips 27M1C5500VL Specifications

General

Haze rate	25 %
Panel type	VA
Color depth	8 bit
Pixel pitch	0.2331 x 0.2331 mm
Pixel density	108.79 ppi
Backlight type	W-LED
Display diagonal	27 \
Surface hardness	3H
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	48 - 165 Hz
Response time (fast)	1 ms
Horizontal scan range	30 - 250 kHz
NTSC coverage (typical)	95.6 %
Screen curvature rating	1500R
Viewable size, vertical	335.664 mm
sRGB coverage (typical)	126.5 %
Contrast ratio (typical)	4000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	68.5 cm
Viewable size, horizontal	596.736 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	2560 x 1440
High Dynamic Range (HDR) technology	High Dynamic Range 10 (HDR10)
Dynamic contrast ratio marketing name	Mega Infinity DCR
Picture enhancement	SmartImage game
Exterior finish type	Textured
Regulatory Approvals	CB; CE Mark; FCC Class B; ICES-003; CU-EAC; EAEU RoHS; TUV/ISO9241-307; TUV-BAUART
Recyclable packaging material	100 %
Mean time between failures (MTBF)	50000 h
Component video sync	Separate sync
HDCP version	1.4/2.2
Headphone out	-
DisplayPort version	1.4
LED indicators	Operation, Stand-by
Tilt angle range	-5 - 20 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR, UKR
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	38.7 W
Doesn't contain	Mercury (element), PVC/BFR
Sustainability certificates	RoHS
Cables included	HDMI, DisplayPort, AC
Package depth	226 mm
Package width	730 mm
Package height	469 mm
Package weight	9200 g
Product color	Black
Market positioning	Gaming
Operating altitude	0 - 3658 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth (with stand)	193 mm
Width (with stand)	611 mm
Height (with stand)	447 mm
Weight (with stand)	5490 g
Depth (without stand)	83 mm
Height (without stand)	366 mm
Weight (without stand)	4180 g
