Mechanical Instructions
EN 11LC8.1U LA 4.
Figure 4-5 Cable dressing (47" models, ME8 styling)
Tape the 8C02 cable (IR Board to SSB) and
the short red tweeter wire together.
I_17741_013.eps
240408
