Alignments
EN 77LC8.1U LA 8.
Option Bit Overview
Below find an overview of the Option Codes on bit level.
Table 8-4 Option codes at bit level (OP1-OP4)
Option Byte & Bit Dec. Value Option Name Description
Byte OP1
Bit 7 (MSB) 128 OPC_MT8280 ON = MT8280 is available
OFF = MT8280 is not available, i.e. DFI is used in case 120Hz (MJC) is enabled
Bit 6 64 OPC_VIRGIN_MODE ON = Virgin Mode (PNP) is available
OFF = Virgin Mode (PNP) is not available
Bit 5 32 OPC_AMBILIGHT_2 0 = AmbiLight is not available
1 = Mono AmbiLight is available
2 = Stereo AmbiLight is available
3 = Reserved
Bit 4 16 OPC_AMBILIGHT
Bit 3 8 OPC_MJC_120HZ_2 0 = MJC (120Hz) is not available
1 = MJC (120Hz) for 768p is available (OP11 must ON too)
2 = MJC (120Hz) for 1080p is available (OP11 must ON too)
3 = Reserved
Bit 2 4 OPC_MJC_120HZ
Bit 1 2 OPC_MJC_60HZ ON = MJC (60Hz) is available
OFF = MJC (60Hz) is not available
Bit 0 (LSB) 1 OPC_PHILIPS ON = Philips set
OFF = Magnavox set
Byte OP2
Bit 7 (MSB) 128 Reserved Not Used (Reserved)
Bit 6 64 OPC_SHOP_MODE ON = Shop mode is available
OFF = Shop mode is not available
Bit 5 32 OPC_LIGHT_SENSOR ON = Light Sensor is available (ActiveControl= OFF, ON, ON w Light sensor)
OFF = Light Sensor is not available (ActiveControl= OFF, ON)
Bit 4 16 OPC_BACKLIGHT_BOOST ON = Backlight boosting is available
OFF = Backlight boosting is not available
Bit 3 8 OPC_BACKLIGHT_DIMMING ON = Backlight Dimming is available
OFF = Backlight Dimming is not available
Bit 2 4 Reserved Not Used (Reserved)
Bit 1 2 OPC_BBD ON = Black Bar Detection is available
OFF = Black Bar Detection is not available
Bit 0 (LSB) 1 OPC_WIDE_SCREEN ON = TV is 16x9 set
OFF = TV is 4x3 set (Provision)
Byte OP3
Bit 7 (MSB) 128 OPC_HDMI_EASY ON = HDMI Easy is available (Provision)
OFF = HDMI Easy is not available (Provision)
Bit 6 64 OPC_CEC ON = CEC is available
OFF = CEC is not available
Bit 5 32 OPC_EPG ON = EPG is available (Provision)
OFF = EPG is not available (Provision)
Bit 4 16 OPC_VCHIP ON = VChip is available (Provision)
OFF = VChip is not available (Provision)
Bit 3 8 OPC_VIEW_FOR_YOU ON = View for you feature is available
OFF = View for you feature is not available
Bit 2 4 OPC_STEREO_DBX ON = Stereo DBX detection is available (Provision)
OFF = Stereo DBX detection is not available (Provision)
Bit 1 2 OPC_LIP_SYNC ON = Lip Sync is available
OFF = Lip Sync is not available
Bit 0 (LSB) 1 Reserved Not Used (Reserved)
Byte OP4
Bit 7 (MSB) 128 OPC_SideAV_SVHS ON = SideAV SVHS is available
OFF = SideAV SVHS is not available
Bit 6 64 OPC_SideAV_CVBS ON = SideAV_CVBS is available
OFF = SideAV_CVBS is not available
Bit 5 32 OPC_AV3_SVHS ON = AV3_SVHS is available
OFF = AV3_SVHS is not available
Bit 4 16 OPC_AV3_CVBS ON = AV3_CVBS is available
OFF = AV3_CVBS is not available
Bit 3 8 OPC_CVI2 ON = CVI2 is available
OFF = CVI2 is not available
Bit 2 4 OPC_REGION_3 0 = NFATA
1 = EU, AP & LATAM
2 = Reserved
3 = Reserved
4 ~7 = Reserved
Bit 1 2 OPC_REGION_2
Bit 0 (LSB) 1 OPC_REGION
