Philips 32PHT4131/12 - 5231 Series 24

EN 86TPN16.3E LA 11.
Styling Sheets
2016-Oct-28
back to
div.table
11.3 5231 series 24"
20210_802.eps
5231 series 24"
Pos No. Description Remarks
0030 Bezel
0040 Rear cover
0050 Stand Assy
1050 Display panel
1053 Panel SSB
1054 Power Supply Unit
1056 IR/LED panel
1077 BlueTooth Module
1176 Remote control Not displayed
1184 Speaker
FOR ELECTRICAL PARTS/ASSEMBLIES SEE WIRING DIAGRAM CHAPTER 9
1053
0030
1077
1184
0040
0050
1054
1056
1050
