7. Input Mode
FHD Preset Mode (VGA/DVI timing support):
Item Resolution H.Freq.(KHz) V.Freq.(Hz) BW(MHz)
1 640x350 31.469 70.086 25.175
2 640x480 31.469 59.94 25.175
3 640x480 35 66.67 30.240
4 640x480 37.861 72.809 31.500
5 640x480 37.5 75 31.500
6 720x400 31.469 70.087 28.322
7 800x600 35.156 56.25 36.000
8 800x600 37.879 60.317 40.000
9 800x600 48.077 72.188 50.000
10 800x600 46.875 75.000 49.500
11 832x624 49.726 74.551 57.284
12 848x480 31 60.000 33.750
13 960x720 56.4 75.000 72.420
14 960x720 44.74 59.973 57.580
15 1024x768 48.363 60.004 65.000
16 1024x768 56.476 70.069 75.000
17 1024x768 60.023 75.029 78.750
18 1024x768 61.08 75.781 86.000
19 1024x768 35.5 43.000 44.900
20 1152x864 53.986 59.985 79.900
21 1152x864 53.783 59.959 81.750
22 1152x864 63.851 70.012 94.499
23 1152x864 67.5 75.000 108.000
24 1152x870 68.681 75.062 100.000
25 1152x900 61.846 66.004 94.500
26 1152x900 71.809 76.149 108.000
27 1280x720 44.772 60.000 74.500
28 1280x720 52.5 70.000 89.040
29 1280x768 47.776 59.870 79.500
30 1280x768 60.289 74.893 102.250
31 1280x800 49.7 59.810 83.500
32 1280x800 62.8 74.930 106.500
33 1280x960 60 60.000 108.000
34 1280x960 75.171 75.021 129.895
35 1280x1024 63.981 60.020 108.000
36 1280x1024 71.691 67.189 117.000
37 1280x1024 76.02 71.448 130.223
38 1280x1024 79.976 75.025 135.000
39 1280x1024 81.13 76.110 135.000
40 1360x768 47.712 60.015 85.500
41 1366x768 47.712 59.790 85.500
42 1440x900 55.469 59.901 88.750
43 1440x900 55.935 59.887 106.500
44 1440x900 70.635 74.984 136.750
Item Resolution H.Freq.(KHz) V.Freq.(Hz) BW(MHz)
45 1400x1050 64.744 59.948 101
46 1440x1050 65.3 60.000 121.750
47 1400x1050 82.278 74.867 156
48 1600x900 55.54 60.000 97.750
49 1600x1200 75 60 162
50 1680x1050 65.29 59.954 146.250
51 1680x1050 64.674 59.883 119.000
52 1920x1080 66.587 59.934 138.500
53 1920x1080 67.5 60.000 148.500
54 1920x1080 67.1584 59.963 173.000
55 1920x1080 67.08 60 172.798
56 1920x1200 74.038 59.950 154.000
UHD Preset Mode (DP/HDMI timing support):
Item Resolution H.Freq.(KHz) V.Freq.(Hz) BW(MHz)
1 3840x2160 53.946 23.900 296.703
2 3840x2160 54 24.000 297.000
3 3840x2160 56.25 25.000 297.000
4 3840x2160 67.432 29.900 296.703
5 3840x2160 67.5 30.000 297.000
6 4096x2160 54 24.000 297.000
7 3840x2160 135 60.000 594.000
Video timing support (HDMI/DVD HD/DVI):
480i,480p,576i,576p,720p,1080i,1080p,4Kx2K(exceptDVI).
NOTES:
• ThePCtextqualityisoptimuminHD1080mode(1920x1080,
60Hz).
• YourPCdisplayscreenmightappeardifferentdependingonthe
manufacturer(andyourparticularversionofWindows).
• CheckyourPCinstructionbookforinformationaboutconnecting
yourPCtoadisplay.
• Ifaverticalandhorizontalfrequency-selectmodeexists,select60Hz
(vertical)and31.5KHz(horizontal).Insomecases,abnormalsignals
(suchasstripes)mightappearonthescreenwhenthePCpower
isturnedoff(orifthePCisdisconnected).Ifso,pressthe[INPUT]
buttontoenterthevideomode.Also,makesurethatthePCis
connected.
• WhenhorizontalsynchronoussignalsseemirregularinRGBmode,
checkPCpowersavingmodeorcableconnections.
• ThedisplaysettingstablecompliestotheIBM/VESAstandards,and
basedontheanaloginput.
• TheDVIsupportmodeisregardedassametothePCsupport
mode.
• Thebesttimingfortheverticalfrequencytoeachmodeis60Hz.
• WhentheinputsourceisComponentorVideo,theInformation
OSDwillbedisplayedslowlythanotherinputsources.
• NomattertheresolutionofComponentsourceorVideosource
input,theresultofZoommodesettingisthesameas1080P
resolution.
