Alignments
EN 104 BP2.2U, BP2.3U8.
Table 8-6 Option code overview
Byte Bit (dec. value) Subject Options Settings (in decimal values) Remarks
1 0 (1) Video Repro Picture Processing 0= No Spider, 1= Spider Spider availability, influences,
digital options.
1 (2)
2 (4)
3 (8) Comb Filter 0= None, 8= 2D Comb (Columbus without DRAM),
16= 3D Comb (Columbus with DRAM)
4 (16)
5 (32) Ambient Light 0= None, 32=Ambi-light Stereo, 64= Ambi-light Mono
6 (64)
7 (128)
8 (256) Dual Screen 0= None, 256= One Tuner DS, 512= Two Tuner DS
9 (512)
10 (1024) MOP 0= Off, 1024= On Matrix Output Processor (or EBILD)
11 (2048) JOP 0= Off, 2048= On Jaguar Output Processor (or EBILD)
Reserved for future use
12 (4096) POD 0= Off, 4096= On
13 (8192) n.a.
14 (16384) n.a.
15 (32768) n.a.
2 0 (1) Sound Repro Acoustic System (Cabinet) 0= None, 1= Entry_ ME5_5W, 2= Entry_ME5_15W, 3= (Soft)Wrap, 4= Top,
5= Entry+, 15= Others
Cabinet design, used for setting dy-
namic audio parameters.
1 (2)
2 (4)
3 (8)
4 (16) Aux Headphone Sound 0= Off, 16= On Dual AC3 sound in Aux available.
5 (32) n.a.
6 (64) n.a.
7 (128) n.a.
8 (256) n.a.
9 (512) Sub woofer Internal 0= Not Present, 512= Present
10 (1024) Centre Mode Support 0= Not Supported, 1024= Supported
11 (2048) n.a.
12 (4096) n.a.
13 (8192) n.a.
14 (16384) n.a.
15 (32768) n.a.
3 0 (1) Source Select HDMI1 0= None, 1= With analog audio, 2= Without analog audio
1 (2)
2 (4) HDMI2 0= None, 4= With analog audio, 8= Without analog audio
3 (8)
4 (16) n.a.
5 (32) USB Version 0= None, 32= USB 1.1, 64= USB 2.0 + Card reader USB support.
6 (64)
7 (128) IEEE1394 0= Not Present, 128= Present
8 (256) Ethernet 0= LAN not present, 256= LAN present
9 (512) n.a.
10 (1024) S/PDIF Inputs 0= None, 1024= 1 Connector, 2048= 2 Connectors
11 (2048)
12 (4096) LCOS I/O 0= Not Present, 4096= Present
13 (8192) n.a.
14 (16384) n.a.
15 (32768) n.a.
4 0 (1) Region Region 0= EU, 1= AP-P, 2= AP-N, 3= US, 4= Latam
1 (2)
2 (4)
3 (8) Interconnect China IF 0= Off, 8= On
4 (16) Alternative Tuner 0= Philips, 16= Alps Tuner make.
5 (32) Tuner Type 0= TD1336s (B-Chassis US), 32= TD1331(J-Chassis US),
64= UV1318 (Analogue EU), 96= TD1316 (Hybrid EU)
Tuner type
(B-chassis US is e.g "BP2.3U").
6 (64)
7 (128) Source Select n.a.
8 (256) AV1 0= CVBS/RGB, 256= CVBS/YC/LR, 512= CVBS/YC/YPbPr/HV/LR Input type.
9 (512)
10 (1024) AV2 0= CVBS/YC/RGB/P50, 1024= CVBS/YC/LR Input type.
11 (2048)
12 (4096) AV3 0= Not Available, 4096= CVBS, 8192= YPbPr Input type.
13 (8192)
14 (16384) AV4 0= Not Available, 16384= YPbPr Input type.
15 (32768)
