Technical Specifications, Connections, and Chassis Overview
EN 2 BP2.2U, BP2.3U1.
1. Technical Specifications, Connections, and Chassis Overview
Index of this chapter:
1.1 Technical Specifications
1.2 Connection Overview
1.3 Chassis Overview
Note: Data below can deviate slightly from the actual situation,
due to the different set executions.
1.1 Technical Specifications
1.1.1 Vision
Display type : Plasma
Screen size : 42” (107 cm), 16:9
: 50” (127 cm), 16:9
Resolution (HxV pixels) : 1024(*3)x768p (42”)
: 1366(*3)x768p (50”)
Contrast ratio : 3000:1
Light output (cd/m
2
) : 1000 (BP2.3)
: 1100 (BP2.2)
Viewing angle (HxV degrees) : 160x160
Tuning system : PLL
TV Color systems : ATSC
:NTSC
Video playback : NTSC
Cable : Unscrambled digital
cable - QAM
: Digital cable ready -
CableCard
Presets/channels : 100 presets
Tuner bands : VHF
: UHF
: S-band
: Hyper-band
Supported video formats : 640x480i-1fH
: 640x480p-2fH
: 720x576i-1fH(BP2.2)
: 720x576p-2fH(BP2.2)
: 1280x720p-3fH
: 1920x1080i-2fH
Supported computer formats : 640x480 @ 60Hz
: 800x600 @ 60Hz
: 1024x768 @ 60Hz
: 1366x768 @ 60Hz
1.1.2 Sound
Sound systems : AV Stereo
:BTSC
Maximum power (W
RMS
) : 2 x 15
1.1.3 Multimedia
Supported digital media : Compact Flash I & II
: Memory Stick
: Microdrive (upto 2GB)
: SD / mini SD Card
: Multi Media Card
: Smart Media Card
Supported file formats : JPEG
:MP3
:MP3-pro
: Slideshow (.alb)
USB input : USB1.1 (12 Mbps)
1.1.4 Miscellaneous
Power supply:
- Mains voltage (V
AC
) : 100 - 240
- Mains frequency (Hz) : 50/60
Ambient conditions:
- Temperature range (°C) : +5 to +40
- Maximum humidity : 90% R.H.
Power consumption (values are indicative)
- Normal operation (W) : ≈ 400 (42”)
: ≈ 467 (50”)
- Standby (W) : < 2
Dimensions (WxHxD in cm) : 124x68x10.4 (42”)
: 141x78x10.4 (50”)
Weight (kg/lbs) : 42/92.6 (42”)
: 60/132.3 (50”)
1.2 Connection Overview
Note: The following connector color abbreviations are used
(acc. to DIN/IEC 757): Bk= Black, Bu= Blue, Gn= Green, Gy=
Grey, Rd= Red, Wh= White, and Ye= Yellow.
1.2.1 Side Connections
Figure 1-1 Side I/O connections
USB1.1 (only for BP2.3)
Figure 1-2 USB (type A)
1-+5V k
2 - Data (-) jk
3 - Data (+) jk
4 - Ground Gnd H
Mini Jack: Audio Headphone - Out
Bk - Headphone 32 - 600 ohm / 10 mW ot
E_14700_064.eps
071004
SIDE I/O
SVHS
CVBS
R
AUDIO
USB
L
1234
