8 EN
Mount into the
dashboard
• If the car does not have an on-
board drive or navigation computer,
disconnect the negative terminal of
the car battery.
• If the car battery is not
disconnected, to avoid short-circuit,
make sure that the bare wires do
not touch each other.
1 Make sure that the car dashboard
opening is within these
measurements:
2 Remove the mounting sleeve with
the supplied disassembly tools.
183 mm
53mm
5mm
3 Install the sleeve into the
dashboard and bend the tabs
outward to x the sleeve.
4 Slide the unit into the sleeve until
you hear a "click".
183 mm
53.5 mm
