Philips CED1910BT - Smart Connect Link; Universal USB Charging

9
English
EN
Connectors and
sockets on rear panel
External sockets or
connectors
14 OE SWC IR
REMOTE IN (Brown
wire)
OE SWC remote
in
15 OE SWC IR
REMOTE IN (Black
wire)
Ground
16 OE SWC AD LEARN
(White wire)
OE SWC AD
Learn line 1
17 OE SWC AD LEARN
(White wire)
OE SWC AD
Learn line 2
18 OE SWC AD LEARN
(Black wire)
Ground
19 Smart Connect Link
Connector (Black
connector)
Compatible with
external accessory
box (refer to
Chapter 10)
20 External Mic (Black
connector)
External
microphone
21 GPS AERIAL (Black
connector)
GPS smart
antenna
22 FRONT OUT R (Red
connector)
Front right speaker
23 FRONT OUT L
(White connector)
Front left speaker
24 Rear Monitor
Audio Out 1 (white
connector)
Left audio channel
input socket of
one rear monitor
25 Rear Monitor
Audio Out 1 (Red
connector)
Right audio
channel input
socket of one rear
monitor
26 Rear Monitor
Audio Out 2 (White
connector)
Left audio channel
input socket of
another rear
monitor
27 Rear Monitor
Audio Out 2 (Red
connector)
Right audio
channel input
socket of another
rear monitor
Tip
• The pin arrangement for the ISO connectors depends
on the type of your vehicle. To avoid damage to the
system, connect properly.
