Connectors and
sockets on rear panel
External sockets
or connectors
7 VIDEO OUT 1 (Yellow
socket)
Video input
socket of an
external display
device
8 VIDEO OUT 2 (Yellow
socket)
Video input
socket of an
external display
device
9 RADIO ANTENNA
(Green socket)
Radio antenna
10 CAMERA IN (Purple
socket)
Video output
socket of an
external camera
11 SUB-W OUT (Blue
socket)
Sub-woofer
12 REVERSE CAMERA
(Purple wire)
Reverse camera
(B+)
13 PARKING BRAKE
(Pink wire)
Parking brake (-)
14 OE SWC IR REMOTE
IN (Brown wire)
OE SWC
remote in
15 OE SWC IR REMOTE
IN (Black wire)
Ground
16 OE SWC AD LEARN
(White wire)
OE SWC AD
Learn line 1
17 OE SWC AD LEARN
(White wire)
OE SWC AD
Learn line 2
18 OE SWC AD LEARN
(Black wire)
Ground
19 EXTERNAL BOX
CONNECTOR (Black
connector)
External
navigation box
20 External Mic (Black
connector)
External
microphone
21 GPS AERIAL (Black
connector)
GPS smart
antenna
22 FRONT OUT R (Red
connector)
Front right
speaker
23 FRONT OUT L
(White connector)
Front left speaker
Tip
The pin arrangement for the ISO connectors depends
on the type of your vehicle. To avoid damage to the
system, connect properly.
