18 EN
General information
AC power AC 100-240V~, 50/60 Hz
Operation Power
Consumption
32 W
Eco Standby Power
Consumption
<1 W
USB Direct Version 2.0/1.1
Dimensions
- Main Unit
(W x H x D)
500 x 217 x 98 mm
Weight
- Main Unit 2.614 kg
USB playability information
Compatible USB storage devices:
reader to work with this system)
Supported formats:
FAT32 (sector size: 512 bytes)
MP3 bitrate (data rate): 32-320 Kbps and
variable bitrate
Directory nesting up to a maximum of 8
levels
Number of albums/ folders: maximum 99
Number of tracks/titles: maximum 999
ID3 tag v2.0 or later
File name in Unicode UTF8 (maximum
length: 128 bytes)
Unsupported formats:
Empty albums: an empty album is an album
shown in the display.
example, Word documents (.doc) or MP3
not played.
Supported MP3 disc formats
ISO9660, Joliet
Maximum title number: 999 (depending on
Maximum album number: 99
44.1kHz, 48 kHz
Supported Bit-rates: 32~256 (kbps),
variable bit rates
Maintenance
Clean the cabinet
Use a soft cloth slightly moistened with
a mild detergent solution. Do not use a
solution containing alcohol, spirits, ammonia
or abrasives.
Clean discs
When a disc becomes dirty,
clean it with a cleaning cloth.
Wipe the disc from the
centre out.
Do not use solvents
such as benzene, thinner,
commercially available cleaners, or antistatic
spray intended for analogue records.
Clean the disc lens
After prolonged use, dirt or dust may
accumulate at the disc lens. To ensure good
CD lens cleaner or any commercially
available cleaner. Follow the instructions
supplied with cleaner.
DCM3065_51_UM_V1.0.indb 18 3/2/2012 2:08:14 PM
