Philips DCM3065 - Overview of the Main Unit

8 EN
Overview of the main unit
a
 Turn on the unit, or switch to standby
mode, or switch to Eco Power standby.
b SOURCE
 Select a source: CD, FM radio, iPod/
iPhone/iPad, USB, or MP3 link.
c

 Skip to the previous/next track.
 Search within a track.
 Tune to a radio station.
d

 Start or pause play.
 
e

 Stop play.
 Access the iPod/iPhone/iPad menu.
f 
 Adjust volume.
g
 Open/close the disc compartment.
MP
3
-
LINK
FM ANT
lmn
k
d
e
f
g
o
h
i
j
h Display panel
 Show current status.
i Disc compartment door
j 
k Remote sensor
 Detect signal from the remote control.
l
 Connector for a headphone.
m
 Connector for a USB mass storage
device.
n MP3 LINK
 Connector (3.5mm ) for an external
audio device.
o 
 Connect an FM antenna for reception
improvement.
