Philips DTR3000 - Front panel of the Set-top box; Rear panel of the Set-top box

Front panel of the Set-top box
USB port
LED
• Green : Operating
•Red: Standby
Digital display
Rear panel of the Set-top box
AC Mains
HDMI Digital video audio connector
Digital audio connector (S/PDIF)
SCART connector (to TV or VCR/ DVD)
Antenna input
Antenna output (Loopthrough only)
2 31 7 85 964
1
2
3
4
5
6
7
8
9
Shows the current time when theSet-top box is in
standby.
Shows the programme number when the Set-top box is
on.
Shows hard disk activity(recording in progress,pro-
gramme playback,...)
