Reference : SGP_AVS_SW_ATLAS-05-05 Classification : COMPANY RESTRICTED
Version : 0.17 Project : ATLAS_DSW
Status : Proposed Chapter : User Manual
Date : 2006-09-12
Section : Diagnostic Software (Leco+)
© Philips Electronics N.V. 2006 Philips Semiconductors Page 11 of 124
120000: Hardware ID = 0x27 1
Test OK @ 2
3
Example in case the result is an error (DVD+RW 2.1 example): 4
5
DS:> 1100 6
110002: Communication with Analogue Board fails 7
Error @ 8
9
DS:> 10
11
2.3.4 Termination 12
To turn off the command line interface switch off the DVD Recorder. 13
2.4 END-USER/DEALER SCRIPT INTERFACE 14
This interface is used during execution of the script to display output and error messages. 15
The local display will be used to display the output and the error messages. 16
17
2.4.1 Set-up physical interface components 18
Hardware required: 19
• DVD Recorder 20
The DVD Recorder is tested stand-alone: no other equipment than the DVD Recorder is 21
needed. 22
23
2.4.2 Activation 24
Pressing the play-key on the keyboard of the DVD Recorder during power-on activates the 25
dealer script. 26
27
2.4.3 Usage 28
The test requires no user interaction. A number of nuclei will be run before a message is 29
returned indicating if there is a failure in the DVD Recorder (‘’PASS” will be indicated when the 30
product functions OK and “FAIL” when there has been an error during one of the tests). 31
During the execution of this script, a progress indicator is displayed on the display of the DVD 32
Recorder. 33
Note that from the command line interface this script can be started as well, by entering ‘script’ 34
on it. 35
36
2.4.4 Termination 37
To turn off the dealer test, the DVD Recorder must be powered down. 38
