3 DETAILED DESCRIPTION OF AVAILABLE NUCLEI 1
3.1 CODEC HOST CONTROLLER (CHR) 2
Nucleus Name
DS_CHR_DevTypeGet
Nucleus Number 100
Description Retrieves the device id, the module ids and revisions of the Codec and returns
them to the stdout port.
Technical - Determine the codec id by means of comparing version ids of the modules.
- Read the module-id register of every module and display it to the user.
Execution Time Less than 1 second.
User Input None
Error Number Description
10000 Getting the information succeeded
10001 Wrong codec id detected
Example
DS:> 100
010000:
Device ID 7300
Codec ID PNX7350
F-BCU (0x0102) 4.0 INTC (0x011d) 3.0
SIF (0xa04b) 2.0
BOOT (0x010a) 3.1 CONFIG (0x013f) 5.0 RESET (0x0123) 5.0
CLOCK (0x013e) 7.0 DEBUG (0x0116) 0.1 UART0 (0x0107) 1.2
UART1 (0x0107) 1.2
I2C0 (0x0105) 0.1 I2C1 (0x0105) 0.1 GPIO (0x013c) 3.1
SYNC (0x013a) 4.0
OSD (0x0136) 1.0 SPU (0xa00e) 1.1 MIXER (0x0137) 3.0
DENC (0x0138) 5.0 CCIR (0x0139) 2.1 VDEC (0x0133) 1.0
PARSER (0xa00d) 0.0 DV (0xa00c) 0.0
IDE0 (0xa009) 1.2 IDE1 (0xa009) 1.2 SGDX (0xa008) 4.0
BYTE (0xa00b) 1.0 OUTPUT (0xa003) 8.0 ACOMP (0xa000) 8.0
VFE (0xa001) 8.0 VCOMP (0xa002) 8.0 SCR (0xa004) 8.0
SIFF (0xa011) 3.0
PSCAN (0xa05d) 0.1
ADEC (0x0134) 1.1 IR (0x0131) 2.0 AOI (0xa08c) 0.0
PIP (0xa04d) 1.0 AVLINK (0x3601) 2.1 USBLINK(0xa08e) 0.0
MSVD (0xa087) 0.0 FEBCU (0xa05e) 1.0 BM (0xa085) 0.0
BMI (0xa084) 0.0 DISP (0xa04d) 1.0
Test OK @
