Reference : SGP_AVS_SW_ATLAS-05-05 Classification : COMPANY RESTRICTED
Version : 0.17 Project : ATLAS_DSW
Status : Proposed Chapter : User Manual
Date : 2006-09-12
Section : Diagnostic Software (Leco+)
© Philips Electronics N.V. 2006 Philips Semiconductors Page 25 of 124
Nucleus Name
DS_FLASH_CalculateChecksum
Nucleus Number 504
Description Calculate the checksum over all memory addresses. Used to check entire
FLASH contents
Technical - Run the checksum calculation algorithm on all flash memory addresses
Execution Time 6 seconds
User Input None
Error Number Description
50400 Calculating the checksum over all addresses succeeded
Example
DS:> 504
050400: The Checksum = 0xBABE30A4
Test OK @
1
Nucleus Name
DS_FLASH_CalculateChecksumFast
Nucleus Number 505
Description Calculate a checksum over a selected number of address locations
Technical - Run the checksum calculation algorithm on a selected number of flash
memory addresses
Execution Time 6 seconds
User Input None
Error Number Description
50500 Calculating the checksum over selected addresses succeeded
Example
DS:> 505
050500: The Checksum = 0xBABEB064
Test OK @
2
Nucleus Name
DS_FLASH_EraseFlfs
Nucleus Number 506
Description Erase the complete Flash File system segment in flash memory. This will erase
all non volatile data including diversity string and DV unique ID number
Technical - Initialise Flash access
- Search in flash for the segment with the “FLFS” and “FLF2” signature
- Ask the user whether he is sure to erase all data
- If available erase the sector containing the FLFS signature
- If available erase the sector containing the FLF2 signature
Important note: This nucleus will erase all data, make sure to reboot after this and
program a diversity string
Execution Time About 1 second per block erased.
User Input None
Error Number Description
50600 FLFS successfully erased
50601 User aborted the test
50602 FLFS segment is not available
Examples
DS:> 506
Do you readlly want to erase the entire FLFS ? [Y /N(Default)] :y
Erasing FLFS...
050600: All data has been erased
Test OK @
DS:> 506
Do you readlly want to erase the entire FLFS ? [Y /N(Default)] :n
FLFS not erased.
050601: User abort
Test OK @
DS:> 506
Do you readlly want to erase the entire FLFS ? [Y /N(Default)] :y
Erasing FLFS...
050602: No FLFS segment found
Error @
